- Page 1 MCS-SSA [2013030] Installation Guide Ver1.1 ____________________________________________________________________________________ MCS-SSA INSTALLATION GUIDE Page 1 of 6...
-
Page 2: Table Of Contents
MCS-SSA [2013030] Installation Guide Ver1.1 ____________________________________________________________________________________ CONTENTS Specification ............................3 1.1) Absolute Maximum Ratings ....................3 1.2) Power ............................. 3 1.3) Digital Inputs ......................... 3 1.4) Analog Monitoring ........................ 3 1.5) Outputs ........................... 3 Installation Requirements ........................3 2.1) Fuse ............................3 2.2) -
Page 3: Specification
Airflow 2.2) DO NOT obstruct air vents along the front, back and underneath surfaces of the MCS-SSA. Do not install any equipment on top or underneath the MCS-SSA. The above installation requirement must be followed for safe operating and extended product... -
Page 4: System Description
The siren module supports 100W (8 Ohm or 11 Ohm) output speakers. To enable the siren system, turn the Standby switch to Active high at the Operation Switch Input. To activate the siren use the HRT or Airhorn inputs on the siren. -
Page 5: Wiring And Connections
MCS-SSA [2013030] Installation Guide Ver1.1 ____________________________________________________________________________________ 4) Wiring and Connections 4.1) System Bus Connector Name Function Airhorn Negative Input Active Low Ground 11 Ohm Output Output 8 Ohm Output Output Operation Switch Input Active High HRT Negative Input Active low... -
Page 6: Version History
MCS-SSA [2013030] Installation Guide Ver1.1 ____________________________________________________________________________________ Fault Light Diagnosis LED Flashes When There Is A Fault Flashes Troubleshooting Siren current is high or there is a short on loudspeaker circuit. Battery voltage too high or too low. Over temperature or overheating.
