BEDIENUNGSANLEITUNG / ANVÄNDARMANUAL
VERSIONS / MODELLE / MODELLER
60530301
Housing / Gehäuse / Hus
48,5
Copyright © 2014 Standby AB. All rights reserved
Cable / Leitung / Kabel
Mounting / Montage /
Montering
Voltage / Spannung /
Spänning
Dimensions / Masse /
Mått
Interface / Schnittstelle /
Gränssnitt
Operating temperature /
Betriebstemperatur /
Driftstemperatur
Approval / Zertifikate /
Godkännande
Included / Inbegriffen /
Inkluderat
Copyright 2020 Standby AB. All rights reserved
USER MANUAL
P1 Panel
APPROVALS / ZULASSUNGEN / TYPGODKÄNNANDE
Technical Data / Technische Daten / Teknisk Data
PC/PBT
Tolerance
Surface
View
SS-ISO 2768-1
1 m
Surface mount / Außenmontage /
Utvändigt montage
10-30VDC
63 x 29 x 20 mm
CAN
-20°C – +85°C
ECE R10, EMC
Software not included / Software nicht im
Lieferumfang enthalten / Programvara ej
inkluderat
P1 PANEL
Designed in Sweden
Drawn by
Phone
Name
PM
Mounting Bracket
SE05/CEO
Product manager
Phone
PM
Date
Scale
Part.no
2014-09-01
2:1
60590220
AM60530301C
