Standby P4 Manual

P4 - Manual
Thank you for choosing a product from Standby.

Technical Data

Attribute
Housing
Cable length
Supply voltage
Dimensions
Recommended fuse
Interface
Ambient temperature
- Operating
- Storage/transport
Current consumption max
Tests performed
Approval

Included

605303XX 4 Button version
3 Button version

Connection

1
.
2
.
3
.
4.
5.
6
.
AM605303XXA
Units
PC/ABS
100 cm
+10-30VDC
98x33x19 mm
1A
CAN
-40 till +80
-40° till +85°
100mA at operation (0,15mA at standby mode)
Tested according to applicable parts of SS-ISO_16750-3 and SS-ISO_16750-4_2010
ECE R10
1.
2.
3.
1 2 3 4
5 6
4.
5.
6.
www.standby.eu
Connector: JAE IL-AG5-6P-S3C1
Pin: JAE IL-AG5-PC1-5000
Mating connector: JAE IL-AG5-6S-S3C1 (Not included)
Mating sleeve: JAE IL-AG5-C1-5000 (Not included)
Green CAN Low 1
Yellow CAN High 1
Brown CAN Low 2
White CAN High 2
Grey Ground
Pink +10-30VDC
P4 - Manual
© Standby AB
