L56 2C
Thank you for choosing a product from Standby.
Technical Data
Lens
Diodes
Cable
Power
Ambient temperature
Size
Approvals
Included
Synchronizing
Preset Settings
Part number
Color 1
45657058
Blue
45657055
Blue
45687078
Amber
45677077
White
To change the flash pattern setting, see Flash Pattern. To change the sync mode setting, see Sync Mode.
Flash pattern
Color 2
Color 1
Amber
Double
Blue
Double
White
Double
White
Steady
Polycarbonate
8+8 high power LED
2 m, basic version
10-30 V DC
-40ºC to +85ºC
140,2 x 50,5 x 20 mm
Warning light, class 2: ECE R65 (E5)
EMC: ECE R10 (E5)
IP67
1 x L56 Lamp 2C
1 x gasket
1 x assembly kit
12V: Up to 28 LED Lamps
24V: Up to 14 LED Lamps
Sync mode
Color 2
Color 1
Double
Simultaneous
Double
Simultaneous
Steady
Simultaneous
Steady
N/A
1
Standby AB – standbygroup.se
L56 2C – Manual
Color 2
Alternate
Simultaneous
N/A
N/A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Standby L56 2C
Summary of Contents for Standby L56 2C
- Page 1 L56 2C – Manual L56 2C Thank you for choosing a product from Standby. Technical Data Lens Polycarbonate Diodes 8+8 high power LED Cable 2 m, basic version Power 10-30 V DC Ambient temperature -40ºC to +85ºC Size 140,2 x 50,5 x 20 mm...
-
Page 2: Setting The Flash Pattern
L56 2C – Manual Flash Pattern Introduction The flash pattern setting controls the flash pattern. There are several available combinations of flash patterns, see table. Double, Triple, Quad, Single (1Hz), and Steady burn are built-in flash patterns and no control system is needed. - Page 3 L56 2C – Manual 5. Within 1 to 6 sec: temporarily connect the white wire to ground and let it stay connected for at least 2 sec. The lamp enters configuration mode and a flash sequence indicating the current settings starts.
-
Page 4: Setting The Sync Mode
L56 2C – Manual Sync Mode Introduction The sync mode setting controls how the flashing of two or more lamps is synchronized. There are two versions of sync mode: Simultaneous and Alternate. Simultaneous means that the lamps are in sync, that is they come on and go off at the same time. - Page 5 L56 2C – Manual 5. Within 1 to 6 sec: temporarily connect the white wire to ground and let it stay connected for at least 2 sec. The lamp enters configuration mode and a flash sequence indicating the current settings starts.
- Page 6 L56 2C – Manual Factory Reset Introduction The settings can be changed back to the factory settings. The factory settings are like the Preset settings. Reset to Factory Settings WARNING Risk of eye damage. Do not look into the beam at close range.
- Page 7 L56 2C – Manual 5. Within 1 to 6 sec: temporarily connect the white wire to ground and let it stay connected for at least 2 sec. The lamp enters configuration mode and a flash sequence indicating the current settings starts.
- Page 8 L56 2C – Manual Connections The function of each wire and how to connect the wires depend on which version of flash pattern that is selected, see tables below. Table 1. Connections when flash pattern Double or Steady burn is selected.
-
Page 9: Installation
L56 2C – Manual Installation CAUTION The lamp must be mounted on a flat surface. To prevent moisture from entering the lamp through the cable end, make sure that the cable end is sealed or located in a dry part of the vehicle.
