- Page 1 Breeze Installation Manual Installation Manual...
-
Page 3: Delivery Set
Recycle at the end of the service life. Do not dispose the product with unsorted municipal trash. The VKO Axial exhaust series described in this user’s manual is a duct axial fan designed to supply or exhaust ventilation of small and medium-sized premises. - Page 4 The fan is designed for connection to AC 220-240 V, 50 Hz power mains. Air flow direction in the system must match the pointer direction on the fan casing. Ingress protection rating against access to hazardous parts and water ingress: IPX4 The fan is rated for operation at the ambient air temperature from +1 °C up to +40 °C.
- Page 5 STEP 2 - Position the fan in your preferred installation location and mark the position of the holes on the fan where the screws will then be placed. STEP 3 – Drill the holes for the in compliance with the mounting seats on the fan casing and install the fan with screws.
-
Page 6: Wiring Diagram
STEP 5 – Connect the fan to power mains, screw the cable clamp into place. STEP 6 – Connect the wire to the terminal box by following the wiring diagram. Install the retaining clamp back and secure it with the included screws. WIRING DIAGRAM TERMINAL DESIGNATION KEYS AT WIRING DIAGRAMS:... - Page 7 STEP 8 – Connect the air ducts of the corresponding diameter on both sides of the fan. STEP 9 – Turn on mains power.
-
Page 8: Maintenance
MAINTENANCE The product surfaces must be regularly cleaned from dirt and dust. Cut off power supply prior to any maintenance operations. Use a soft cloth or compressed air to remove external dust. To clean internal surfaces, remove the front cover. Thoroughly clean the internal surfaces every 6 months using a damp cloth soaked in mild detergent and water. - Page 12 reeze ation Manual...
