6 - Properties
6.28 Property 0x87 – Key map status
Property ID: 0x87
Property
Binary
Type:
Length: 8 bytes
Get Property: Yes
Set Property: No – values come from key injection.
Starting
0 – if no keys loaded
Value:
If a key has been loaded into the device, then it's bit indicator should be set to 1.
Table 6-8 Key Map Status Bits
Byte Bit 7
1 – TK1
0 MKIFTK
2 – TK2
0
3 – MK1
0
4 – MK2
0
5 – DK1
DKPTM7
6 – DK2
0
7 – DK3
0
8 – DK4
0
A fully loaded reader would return a keymap of: 7E 00 07 00 8C 00 00 00.
iDynamo 5 Gen III| Secure Card Reader | Programmer's Manual (COMMANDS)
Property Description
Bit 6 Bit 5 Bit 4
MFGTK PRODTK
0 0
0 0
0 0
0 0
0 0
0 0
0 0
Page 42 of 48 (D998200587-101)
Bit 3 Bit 2
FINTK DEVTK
0 0
0 0 MFRQMK
0 0
0 DKPTM3 DKPTM2
0 0
0 0
0 0
Bit 1
MTK TMPTK
0 0
MREQMK FREQMK
0 0
0
0 0
0 0
0 0
Bit 0
0
0
0
0
0
0
