Property 0X10 - Interface Type; Property 0X1E - Start Of Message - Magtek iDynamo 5 Gen III Programmer's Manual

6 - Properties
6.9

Property 0x10 - Interface Type

Property ID: 0x10
Property
Byte
Type:
Length: 1 byte
Get Property: Yes
Set Property: Yes (No for devices that switch connections automatically)
Default
Dependent on device type:
Value:
This property represents the device's current connection type.
Valid values for this property are:
•
0x00 = USB HID (HID Only)
•
0x01 = USB Keyboard Emulation (KB) (USB KB Only)
•
0x02 = iAP2
•
0xFF = One-Time Automatic (HID Only | iAP2 Only). When the property is set to this value and
the device connects to a host, the device attempts to determine which interface type the host is
using. After it successfully detects the interface type, it automatically sets this property to the
value that corresponds to that interface type.
6.10 Property 0x1E – Start of Message
Property ID: 0x1E
Property
String
Type:
Length: 0-7 bytes
Get Property: Yes
Set Property: Yes
Default
Null String
Value:
The device sends the value of this property to the host before all other card data. For example, if the host
software requires a set of keystrokes to begin the process of receiving card data, this property could be set
to transmit that keystroke sequence.
iDynamo 5 Gen III| Secure Card Reader | Programmer's Manual (COMMANDS)
Property Description
Property Description
Page 33 of 48 (D998200587-101)
