Bradley Terreon Quadra-Fount MF2949/BIR3 Installation Manual

Installation
Packing List
•
•
•
IS
T H
E •
S ID
U P
215-1374 Rev. P: ECO 20-00-008
© 2020 Bradley
Page 1 of 13 9/24/2020
IMPORTANT!
Read this entire installation manual to ensure proper installation. When
finished with the installation, file this manual with the owner or maintenance
department.
Separate parts from packaging and make sure all parts are accounted for
before discarding any packaging material. If any parts are missing, do not
begin installation until you obtain the missing parts.
Water supply requires a flowing pressure of at least 20 psi, but no greater
than 80 psi.
Make sure that all water supply lines have been flushed and then completely
turned off before beginning installation. Debris in supply lines can cause
valves to malfunction.
Hardware supplied by installer must be appropriate for wall construction. Wall
anchors used must have a minimum pull-out rating of 1,000 lb.
Product warranties may be found under "Product Information" on our web
site at www.bradleycorp.com.
Installation
MF2949/BIR3
Terreon Quadra-Fount
®
Wall-Hung Washfountain with
Battery Operated Infrared Control
(Standard*, Juvenile* and OBC Height)
* Standard and Juvenile Height are ADA/TAS Compliant
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Parts Included with the Quarda-Fount
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . .9-10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-13
