Read this entire installation manual to ensure proper
installation.
Flush all the water supply lines before making connections.
Wall anchors used must have a minimum pull-out rating of
1,000 lbs.
File these instructions with the owner or maintenance
department.
Product warranties may be found under "Product
Information" on our web site at www.bradleycorp.com.
215-1480 Rev. E; EN 06-915
© 2007 Bradley Corporation
Page 1 of 20
2/8/07
Installation
Instructions
MG-2/TT
Express® Lavatory
System - MG-Series
with TouchTime ® Control
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . .2
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Installation Instructions . . . . . . . . . . . . . . . . . . 5-12
Cleaning and Maintenance . . . . . . . . . . . . . . . . . .13
Assembly of Components . . . . . . . . . . . . . . . .14-16
Solenoid Valve Troubleshooting . . . . . . . . . . .17-18
Vernatherm™ Valve Maintenance . . . . . . . . .19-20
Cleaning the Strainer . . . . . . . . . . . . . . . . . . . .19-20
IMPORTANT
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY
http://www.bradleycorp.com
FAX 262-251-5817
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bradley MG-2/TT
Summary of Contents for Bradley MG-2/TT
-
Page 1: Table Of Contents
© 2007 Bradley Corporation Page 1 of 20 2/8/07 Installation Instructions MG-2/TT Express® Lavatory System - MG-Series with TouchTime ® Control Table of Contents Pre-Installation Information ....2 Dimensions . -
Page 2: Pre-Installation Information
Barrier-free and ADA compliant - standard height mounting The MG-2/TT Express® Lavatory System must have a rim height no higher than 34" above finished floor to be compliant with Americans with Disabilities Act (ADA). When mounted at 34" rim height, the MG-2/TT Express®... - Page 3 Installation Instructions MG-2/TT Express® Lavatory System Dimensions *39" (991) *33-1/2" (851) *Subtract 4" from vertical dimensions for compliance with ADA guidelines for children's use. Bradley Corporation • 215-1480 Rev. E; EN 06-915 Express® Lavatory System - MG-Series with TouchTime® Control 54"...
-
Page 4: Dimensions
Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Installation Instructions Dimensions continued . . . 35-1/2" (902) TAS Juvenile Height 30" (762) Grades Pre-K thru 5 or 6 FLOOR 14" 26" (356) (660) 37-1/2" (952) TAS Juvenile Height 32"... -
Page 5: Installation Instructions
Step 1: Rough in supplies and optional hot water heater NOTE: See Figure 1 (below), 1a, 1b (for TAS on page 6) and Figure 2 (on page 7) when roughing in the MG-2/TT Express®. IMPORTANT: Flush the supply lines before making connections. Debris in supply lines will cause the valves to malfunction. - Page 6 Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT TAS - Texas Accessibility Standards: Juvenile Height (grades Pre-K thru 5 or 6) APPROX. DIMENSION RECOMMENDED 240V/208V OR 277V FOR OPTIONAL ELECTRICAL BOX LOCATION (4"l x 3"w x 4"h) 28" (711) 22-1/2"...
- Page 7 COLD SUPPLIES OR TEMPERED SUPPLY. STUB OUT 2" Figure 2 Bradley Corporation • 215-1480 Rev. E; EN 06-915 Express® Lavatory System - MG-Series with TouchTime® Control 1-1/2" NPT DRAIN STUB OUT 2" TRANSFORMER LOCATION 2/8/07 MG-2/TT 110 VOLT GFCI ELECTRICAL OUTLET...
- Page 8 Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Installation Instructions continued . . . Step 3: Mount frame to wall 1. Loosen, but do not remove the three bottom access panel screws. 2. Remove the two top access panel screws and washers securing the access panel to the frame and remove the access panel (see Figure 3).
- Page 9 Bradley Corporation • 215-1480 Rev. E; EN 06-915 Express® Lavatory System - MG-Series with TouchTime® Control FRAME SPRAYHEAD 1/4"-20 x 1/2" PAN HEAD SCREWS AND WASHERS (2) PLACES BACK VIEW MG-2/TT 3/8" BOLT AND WASHER BOWL TERREON® END CAP (L) 2/8/07...
- Page 10 Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Installation Instructions continued . . . Step 5: Connecting supply 1. Loosen but do not remove the two mounting screws holding the valve bracket to the frame. Slide the valve bracket up until the larger cutout in the frame’s slot aligns with the screw head (see Figure 5b).
- Page 11 ELECTICAL BOX LOCATION, 4" x 4" WATER HEATER SCREWS BRACKET (140-945) REMOVE (2) SCREWS FROM BACK OF WATER HEATER. ATTACH BRACKET WITH Figure 6a SCREWS AS SHOWN. FOR CLARITY, BOWL NOT SHOWN. COLD WATER SUPPLY OPTIONAL 240V/208V ELECTICAL BOX LOCATION, 2-1/2" x 4" 2/8/07 MG-2/TT...
-
Page 12: Installation Instructions
3. Align the mounting screws with slots on the frame. Valve bracket slides down to lock into place. 4. Turn on the water supply to the MG-2/TT Express® and check for leaks. 5. Turn on the electrical power, trigger the TouchTime ® push buttons and check for proper function (the timing is electronically controlled and set at 15 seconds). -
Page 13: Cleaning And Maintenance
Cleaning and Maintenance Instructions IMPORTANT: Strong alkaline or acid-based chemicals and cleansers should not be used to clean the MG-2/TT Express®. If these chemicals come in contact with the Terreon® surface, wipe off the surface immediately and flush with soapy water. Avoid unnecessary or prolonged contact with hot pans and objects. -
Page 14: Assembly Of Components
Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Assembly of Components END CAP (LEFT) (PART NUMBER VARIES WITH COLOR OF UNIT. CONTACT YOUR LOCAL BRADLEY REP. FOR ASSISTANCE). STAINLESS STEEL ACCESS PANEL 186-1263 Figure 8 2/8/07 Installation Instructions SPRAYHEAD BODY (PART NUMBER VARIES WITH COLOR OF UNIT. - Page 15 Figure 9 SPRAYHEAD BODY Figure 10 Bradley Corporation • 215-1480 Rev. E; EN 06-915 Express® Lavatory System - MG-Series with TouchTime® Control FRAME SPRAYHEAD AERATOR ASSEMBLY S05-166 MOUNTING LOCATION TO BOWL (3) PLACES 2/8/07 MG-2/TT 5/16" I.D. BRAIDED HOSE 269-1365...
-
Page 16: Assembly Of Components
Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Assembly of Components continued . . . TouchTime® and Aerator/Access Plate Assemblies SPACER 182-115 TOUCHTIME® SWITCH (15-SECOND) S83-139B ACCESS PLATE/AERATOR ASSEMBLY S05-166 AERATOR/HOUSING-FLOW Figure 11 Other replacement parts 110-24 VAC CLASS II... -
Page 17: Solenoid Valve Troubleshooting
• pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor (see page 18). Bradley Corporation • 215-1480 Rev. E; EN 06-915 Express® Lavatory System - MG-Series with TouchTime® Control 2/8/07 MG-2/TT... - Page 18 Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Solenoid Valve S07-067 (closed body) and S07-067A (thru body) Figure 12 2/8/07 REF. QTY. PART NO. 118-307 118-307A 269-983 269-577 269-578 269-1729 269-1730 269-579 160-447 125-165 Bradley Corporation • 215-1480 Rev. E; EN 06-915...
-
Page 19: Vernatherm™ Valve Maintenance
Solution: Adjust the temperature. Using a blade screwdriver, turn the adjustment stem counterclockwise to increase the temperature or clockwise to decrease the temperature. Bradley Corporation • 215-1480 Rev. E; EN 06-915 Express® Lavatory System - MG-Series with TouchTime® Control 2/8/07 MG-2/TT... - Page 20 Express® Lavatory System - MG-Series with TouchTime® Control MG-2/TT Vernatherm™ Thermostatic Mixing Valve (S01-524) Repair Kit S65-259 Item Description Thermostat O-Ring O-Ring Strainer (173-028) Figure 13 Tempered Line Adapter Assembly (S39-685) Option Figure 14 Strainer 173-028 2/8/07 Bradley Corporation • 215-1480 Rev. E; EN 06-915...
