Specifications
Capacitance
Frequency
(Electronic)
Frequency
(Electrical)
Duty Cycle
#NAS100177; r. AD/97993/98002; en-US
60.00 nF
600.0 nF
6.000 µF
60.00 µF
600.0 µF
6.000 mF
60.00 mF
99.99 mF
Notes: < 99.99 nF is not specified.
9.999 Hz
99.99 Hz
999.9 Hz
9.999 kHz
99.99 kHz
999.9 kHz
9.999 MHz
Notes: Sensitivity: 0.8 V RMS minimum at 20 to 80% duty cycle and
< 100 kHz; 5 V RMS minimum at 20 to 80% duty cycle and < 100
kHz.
10.00 to 1 kHz
Sensitivity:
AC mV range (≥ 100 mV).
AC V range (≥ 6% of range).
6000µA / 600.0mA / 10.00A ranges (≥ 6% of range).
600.0µA / 60.00mA / 6.000A ranges (≥ 60% of range).
0.1 to 99.9%
Pulse width: 100 µS to 100 ms (frequency: 5 Hz to 150 kHz
0.01 nF ±(5.0% + 20 digits)
0.1 nF ±(4.0% + 5 digits)
0.001 µF
0.01 µF
0.1 µF
0.001 mF ±(10.0% of reading)
0.01 mF
0.01 mF
0.001 Hz ±(1.0% + 5 digits)
0.01 Hz
0.1 Hz
0.001 kHz
0.01 kHz
0.1 kHz
0.001 MHz
0.01 Hz ± (0.5 % of reading)
0.1%
± (1.2 % + 2 digits)
