Table of contents

1 Introduction........................................................................1
2 Safety ................................................................................2
2.1 International Safety Symbols ......................................... 3
2.2 Input Protection Limits ................................................. 3
2.3 FCC Compliance ........................................................ 4
3 Product Description ............................................................5
3.1 Meter Front ............................................................... 5
3.2 Meter Back ............................................................... 6
3.3 Button Descriptions..................................................... 7
3.4 Display Description ..................................................... 8
4 Meter Power .......................................................................9
4.1 Automatic Power Off (APO)........................................... 9
5 Operation ......................................................................... 10
5.1 Automatic and Manual Range ..................................... 10
5.2 MODE Button .......................................................... 10
5.3 LCD Backlight.......................................................... 11
5.4 Maximum and Minimum Readings................................ 11
5.5 Relative (REL) Mode ................................................. 11
5.6 Data Hold ............................................................... 11
5.7 AC/DC Voltage (Frequency, Duty Cycle)
Measurements ......................................................... 12
5.7.1
5.8 10 A AC/DC Current Measurements ............................. 14
5.8.1
5.9 µA, mA AC/DC Current Measurements.......................... 15
5.9.1
5.10 Resistance Measurements ......................................... 17
5.11 Continuity Test ......................................................... 18
5.12 Diode Test............................................................... 19
5.13 Capacitance Measurements ....................................... 21
5.14 Frequency and Duty Cycle Measurements
(Electronic) ............................................................. 22
5.15 Type K Thermocouple Temperature
Measurements ......................................................... 23
#NAS100177; r. AD/97993/98002; en-US
Frequency and Duty Cycle of AC Voltage
Measurements .............................................. 13
Frequency and Duty Cycle of 10 A AC Current
Measurements .............................................. 14
Frequency and Duty Cycle of µA and mA AC
Current Measurements.................................... 16
ii
