5
Operation
6. The diode or junction can be evaluated as follows.
• If one reading is between 0.400 V and 0.700 V, and the other reading is
OL, then the diode is good.
• If both readings are OL the device is bad (open).
• If both readings are very low or zero, the device is bad (shorted).
#NAS100177; r. AD/97993/98002; en-US
20
