CLAMPRCB | Remarkable Creator™ Pro+Plus with Clamp Mount
TAB001
HD011
GN03122
Attach the mount clamp by rotating the C-Clamp knob. Use
a Phillips screwdriver to adjust the clamp bracket position.
Optionally, slide a rubber boot onto the top of the mount's
clamp to prevent scratches if preferred.
Rubber
Clamp Boot
C-Clamp
C-Clamp Knob
Remove the tightening ring from the holder. Position the
ring onto the 17mm end of the mount and snap the holder
onto the ball. Adjust to your preferred position, then secure
the ring tightly.
Tightening Ring
SP-SBH-KIT-22
SP3RMPROPL
SP25MMCAM
SPLEDRING
MG005WR
Clamp
Bracket
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm PST
Includes:
1 – Slim-Grip
®
Tablet Holder Kit
(TAB001)
1 – 22mm Ball Clamp Post Mount
1 – Clamp Base for Pro Stand
(HD011)
1 – Mobile Grip 5 Universal Phone Holder
1 – Triple Shaft Overhead Arm
(SP3RMPROPL)
1 – 25mm Ball to 1/4-"-20 Camera Adapter
1 – Rechargeable Clip-On LED Ring Light
1 – 22mm Ball to Dual T-Tab Adapter Kit
Optional - (1) Rubber Clamp Boot
Clamp opening: 0" - 3" (0mm - 76mm)
IMPORTANT: For the tablet holder, select the appropriate short or long support
legs and install to holder. For large devices, select 4 long support legs.
Attach the overhead arm assembly to the clamp pedestal by
loosening the collar at the pole's top until the metal ball side
1
of the overhead arm assembly fits into the collar. Then,
tighten the collar clockwise to secure it in place.
Metal
Ball side
Collar
Adjustment Collar
Place the phone in the holder using both hands. Insert the
device by pushing it into one of the spring-loaded support
arms. Then, expand the other support arm and insert the
device completely.
*Phone not included
arkon.com
Designed in USA
©Arkon Resources, Inc.
(GN03122)
(MG005WR)
(SP25MMCAM)
(SPLEDRING)
(SP-SBH-KIT-22)
Tightening
Knob
Continued on page 2
Need assistance?
Scan to email our
Arkon® customer
service team.
rev.041024
