Arkon Remarkable Creator Pro Manual

|
CLAMPRV29PK Arkon Pro Stand Clamp Mount for Phone or Cameras – Pink
Your Pro Stand Clamp Mount will arrive in four parts:
SPHD8L29PINK
Pink Telescoping
Pole
SPHD8L29CLAMP
Clamp Base
Attach mount to surface by tightening C-clamp knob. Slide optional
1
a
rubber clamp boot onto the top of the mount's clamp to prevent
scratching clamp surface if desired.
Rubber Clamp Rubber Clamp
Boot Boot
C-Clamp C-Clamp
Attach overhead arm assembly to clamp pedestal by unscrewing the
2
collar at the top of the pole until the metal ball side of the overhead
arm assembly fi ts into the collar. Tighten collar clockwise to secure. sembly fits into the collar. Tighten collar clockwise to secure.
Adjustment Collar
MG005WR
Phone Holder
SP3RMPR0PL RMPR0
SP25MMCAM
Overhead Arm
25mm to 1/4"-20
Assembly
Camera Bolt Adapter
(optional)
Clamp Bracket Clamp Bracket
C-Clamp Knob C-Clamp Knob
y unscrewing the
til the metal ball side of the overhead
Tightening g g g g g
Knob
Metal
Ball side e e e e e e e
Collar
MG005WR
SP3RMPR0PL
SPHD8L29PINK
SPHD8L29CLAMP
Assembled Mount
For thicker tables or desks, adjust the clamp bracket by using a Phillips
1
b
screwdriver to remove the screws from the top position and move
them to the lower positions.
Screws
Unscrew tightening ring from holder. Place ring over the 17mm end of
3
mount then snap the holder onto the ball. Set to desired position, then
tighten ring.
Tightening Ring
rev.122220
Telescoping pole extends upward from
17 inches to 29 inches.
Adjustable clamp opens from 1.5 to
3.25 inches.
Compatibility:
Holder fi ts smartphones measuring up
to 3.9" wide.
Adapter compatible with cameras
having 1/4"-20 pattern.
IMPORTANT:
Do not overtighten ring. Overtightening
ring may damage threads on holder.
Screws
Continued on page 2
