Arkon RoadVise KNRMCPM Manual

KNRMCPM | RoadVise
1
Install the RoadVise
to 25mm ball adapter mount
To begin the installation, find the packaging with the 4-hole
AMPS to 25mm ball adapter plate and the RoadVise phone
holder, which includes foam padding and installation hardware.
Next, attach the four mounting screws by inserting them
through the 4-hole AMPS to 25mm ball adapter plate and into
the phone holder.
3
How to adjust the Robust™ Clamp Mount
Turn the knob on the clamp mount counterclockwise to expand
the clamp arms to your desired width. Expand the arms by
gently pulling them apart. Mount to your application surface
and tighten the knob clockwise to secure.
Ultra Robust Clamp Phone and Tablet Mount with Security Knob
®
KNRMCPM
Ultra phone holder to the 4-hole AMPS
®
Includes:
1 – Manual
1 – RoadVise
1 – 4-hole AMPS to 25mm Ball Adapter
1 – Robust™ Series 3.75 inch Composite Shaft
1 – Robust™ Clamp Mount with Security Knob
Important: Clean the application surface and make sure
it is free of dirt, dust, and grease before installing the
mounting hardware.
2
Assemble the components
Locate the clamp mount and shaft arm. Loosen the knob
to allow the ball adapters to insert into the shaft arm by
turning it counterclockwise. Insert the ball mounts to either
end of the shaft arm and turn the knob clockwise to tighten.
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm PST
Ultra Phone and Tablet Holder
®
(APAMPS25MM)
arkon.com
Designed in USA
©Arkon Resources, Inc.
(RVKNAMPS)
(SP-RM250)
(CPM01B)
Need assistance?
Scan to email our
Arkon customer
®
service team.
