Modular Closets MILANO Assembly Instructions Manual page 21

Assembly and Installation Manual
Step 9a
Open box 3 and drill in the side connecting bracket on the shared sidepanel ( )
B
(H5) x 3
(H9) x 1
B
3/8" flat-head
left
screw
side connecting bracket
Pack 03
B
Step 9b
Drill in the metal srew dowels on the shared sidepanel ( )
B
(H3) x 30
(H3) x 15
B
metal screw
wedgefix
dowel
dowel
Pack 03
B
35
when building tall hanging
see step 4
3
2 1
21
