DIGITAL-LOGIC AG
9.2.3 Hardware type
Function:
HARDWARE TYPE
Number:
EAh
EPP-Version:
included since version V3.0.
Description:
Returns to the MICROSPACE Product code.
Input Values:
AH = EAh Function Request
Output Values:
AH = Board Size: M = PC/104 (MSM)
Output Values:
AL = CPU Type
The next registers specify the type of CPU-Board:
BH=
BL=
CH=
CL=
All other registers are preserved.
9.2.4 Watchdog functions
Function:
WATCHDOG
Number:
EBh
EPP-Version:
included since version V3.01.
Description:
Enables, strobes and disables the watchdog. After power-up, the watchdog is
always disabled as the BIOS does not send strobes to the watchdog. Once the
watchdog has been enabled, the user application must perform a strobe at least
every 800ms, otherwise the watchdog performs a hardware reset.
Input Values:
AH = EBh Function Request
AL = Disable / Enable and strobe
Output Values:
none; all registers are preserved.
E = Euroboard 3U (MSE)
W = Workstation 1 or 2 (WS)
2 = 286
4 = 486
5 = P5
6 = P6
...
'V' 'D' '1'
'1'
0
'X' 0
'0'
0
0
0
0
0
0
0
0
of the watchdog
55
'2'
...
0
...
0
...
0
...
0 = Disable
1 = Enable and strobe
MSM486V Manual V3.22
