REVEX
2PH from 30A to 40A

9.1 Menu navigation

The menus are accessible using the control panel keypad and display.
Control Panel Display and Keys are Not present for Option Codes: 2/3 (see table pag. 15)
HOME PAGE
Iout0.0A
Iout0.0A
SP 100%
Iout0.0A
SP 100%
Iout0.0A
SP 100%
SP 100%
(~2 sec)
To access a menu and edit a setting:
1. Press and hold Local/Remote and Function together
Menu.
2. Press Up to choose the menu. (Press down
3. Press function
4. Use up and/or down
5. Press function
6. Press Up to advance to the next parameter and repeat to reach the desired parameter.
7. Press function
8. Use Up and/or down
9. Press function
10. Press and hold local/remote and function together
menus.
Menu Password
Operator 0
Setup 2
Adv Setup 10
Hardware 5
Comm 3
Monitoring 0
Choose
Menu
+
Menu
Menu
Operator Menu
Operator Menu
Operator Menu
Operator Menu
Operator Menu
Operator Menu
Operator Menu
Operator
Operator
(wrong password)
+
(~2 sec)
to advance to the password prompt.
to set the password (see the table).
to enter the password and advance to the first parameter of the menu.
to start editing the parameter. The parameter name flashes in the upper display.
to edit the parameter setting.
to enter the new setting. The parameter name stops flashing.
Parameter used to...
View measured values and basic settings including current, voltage and set
point
Configure the power controller for the load
Configure the operation and performance of the power controller in the
application
Configure the functions of the analog and digital inputs and outputs, and the re-
transmission parameters
Configure field bus communicating parameters
View measured and calculated values and other read-only parameters
Enter Choose
Password Parameter
Password
0
Set Point
Set Point
100% Set Point
100% Set Point
100%
100%
+
if you overshoot the menu you want).
+
26
User's manual
Edit
Parameter
Set Point
100%
Set Point
Set Point
100% Set Point
100% Set Point
100% Set Point
100%
100%
until the upper display flashes
for about two seconds to exit the
