REVEX
2PH from 30A to 40A
TOP VIEW
SYNC
1 2 3 4 5 6 7
8.2.1 SSR Control Input schematic
For SSR input use follow the schematic below and configure Digital Input 1 as Fast Enable.
14
8
SSR
INPUT
M1
M3
Analog Input 1
9
11
10
12
DOWN VIEW
L1
T1
13
* SSR Input:
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc)
3HZ Max on time min. 100 ms
23
User's manual
M2
L3
T3
