Thor Broadcast H-4SDI-ATSC-IP-LL Quick Setup Manual page 4

Enable VCT Insert (optional)
Click "General"
Check Box to enable VCT Insert
Step 5: IP Preferences
IMPORTANT:
TO ACCESS STREAMS, CONNECT
DEVICES TO THE DATA PORT USING
AN ETHERNET CABLE
Select "Output Settings" from the main menu
Click the pencil
icon to edit
From the popup window, you can
enable and edit your IP preferences
Click "Apply" to
Connect to the stream
save changes
using the appropriate IP
and Port Number
Example:
udp://@224.2.2.2:3000
