H-8HDMI-IPCAST
Step 1: Connections
Connect included
power supply
NMS 1: (192.168.1.137)
Connect the NMS port to your PC using
an Ethernet cable
NMS is for management and Data
stream outputs (do not use Data ports)
Step 2: Encoding
Repeat these steps as needed for all channels
https://thorbroadcast.com
1
2
3
1). Select "Encode"
from the Main Menu
3). Video Lock and Encryption status must be green
800-521-8467
HDMI INPUTS
4
5
6
Open web browser and go to:
http://192.168.1.137 for NMS 1
http://192.168.1.138 for NMS 2
Login/Password: admin/admin
2). Select Channel
5). Click "Apply"
to save changes
sales@thorfiber.com
Quick Setup Guide
7
8
NMS 2: (192.168.1.138)
4). Bitrate may be
adjusted from 1-13 Mbps
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Thor Broadcast H-8HDMI-IPCAST
Summary of Contents for Thor Broadcast H-8HDMI-IPCAST
- Page 1 800-521-8467 sales@thorfiber.com H-8HDMI-IPCAST Quick Setup Guide Step 1: Connections HDMI INPUTS Connect included power supply NMS 1: (192.168.1.137) NMS 2: (192.168.1.138) Open web browser and go to: Connect the NMS port to your PC using http://192.168.1.137 for NMS 1 an Ethernet cable http://192.168.1.138 for NMS 2...
- Page 2 Step 3: Streaming 1). Select “StreamServer” from the Main Menu 2). Check boxes to enable/disable RTSP, HTTP and/or HLS streaming 3). Click “Apply” 4). Select Channel to save changes 5). Stream Name may be changed to preference 6). Check box to enable/disable UDP streaming 7).
- Page 3 Press “Save config” button Confirmation message will appear briefly until saving is complete. Scan for more info: NOTE: NMS 1 and NMS 2 are independent systems. Each one must configured and saved individually. H-8HDMI-IPCAST Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
