H-2HDMI-QAM-IPLL
This guide also applies to model: H-1HDMI-QAM-IPLL
Step 1: CONNECT AND LOGIN
Connect the NMS port to your PC using an ethernet cable
Open web browser and go to http://192.168.0.136
Login/Password: admin/admin
Step 2: Encoders
https://thorbroadcast.com
NMS
Select "Encoder 1"
from the main menu
800-521-8467
Recommended Settings:
Video Format: MPEG2
Video Bitrate: 18.0
Audio Format: AC3
Click "Apply" to
save changes
Repeat these steps as needed for Encoder 2
sales@thorfiber.com
Quick Setup Guide
Connect Power Supply
Green light
indicates proper
input connection
Advertisement
Related Manuals for Thor Broadcast H-1HDMI-QAM-IPLL
Summary of Contents for Thor Broadcast H-1HDMI-QAM-IPLL
- Page 1 800-521-8467 sales@thorfiber.com H-2HDMI-QAM-IPLL Quick Setup Guide This guide also applies to model: H-1HDMI-QAM-IPLL Step 1: CONNECT AND LOGIN Connect Power Supply Connect the NMS port to your PC using an ethernet cable Open web browser and go to http://192.168.0.136...
- Page 2 Step 3: Modulator Settings Select “Modulator” Select top Pencil from the main menu icon to edit all Select Pencil icon on the same line to Status lights edit individually must be green Check box to Select desired enable channel frequency and channel Click “Apply”...
- Page 3 Step 4: TS Config Select “TS Config” Click “Parse program”. from the main menu Detected programs will appear in the left pane. Select Output (1-4) Programs assigned to output Check the box to will appear in right pane Click “ ”...
- Page 4 Step 6: SAVE CONFIGURATION Click “Configuration” on the Main Menu Click the “Save” tab Press “Save config” button Scan for more info: Confirmation message will appear briefly until saving is complete. H-2HDMI-QAM-IPLL Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
