product information (e.g. certification information) and may not be removed or damaged. In case of a
label wear-out, contact ELATEC.
In addition, once an RFID module (TWN4 Palon Compact M series) has been integrated into a host
device, the label might not be visible anymore. In this case, specific requirements related to the labeling
of the host device might apply. For more information, refer to the integration manual of your RFID
module and to the documentation related to the host device.
3.5

SCOPE OF DELIVERY

The RFID readers and modules of the TWN4 Palon Compact family are delivered as a kit with the
following components:
3.5.1 TWN4 PALON COMPACT PANEL KITS
© 2024 – ELATEC GmbH – TWN4 Palon Compact family – user manual – DocRev01 – EN – 05/2024
RFID module
Depending on the product configuration, a TWN4 Palon
Compact Panel kit can be delivered with any RFID module of the
TWN4 Palon Compact family (refer to Chapter "TWN4 Palon
Compact M series")
Housing kit
The housing kit delivered with TWN4 Palon Compact Panel
includes an IP65 protected, transparent polycarbonate housing,
2 inner holder clips and a black polycarbonate outer mounting
frame.
Locknut
ABS locknut M63 x 1.5
Material: nylon
O-ring seal
Dimensions: 65.00 x 2.00 mm / 2.55 x 0.07 inch
Material: nitrile butadiene rubber (NBR)
