Haztec 4-3056-STT Manual

4-3056-STT 6-LED
Slim Stop/Tail/Turn Light
Thank you for purchasing this Haztec product. Before proceeding with installation, it is essential to
read and understand this instruction booklet.
▪ This product must be installed by persons competent in vehicle electrical installations
▪ Care should be taken to ensure that water ingress cannot occur through mounting or
wiring holes
▪ Regularly inspect the product to confirm correct operation
▪ DO NOT stare directly into the light it produces as permanent damage to the eyes
may result
▪ Use only a mixture of soap and water to clean this product
▪ DO NOT allow solvents, fuels, acetone-based cleaners etc. to contact with this product
Basic Operating Specifications:
Supply voltage range:
Maximum current draw:
Operating temperature range:
LED Power:
Dimensions (mm):
Cable length:
Weight:
M390.1.0
10-30VDC
Stop
Tail
Turn
O
-40 C ~ +65
1W per LED
130 (L) x 28.5 (H) x 13 (D)
200mm
84g
Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: +44(0)113 202 9115 ∙ info@haztec.uk ∙ www.haztec.uk
▪ Ultra slim LED stop/tail/turn light
▪ 12/24VDC
▪ 6-LED
▪ UNECE R6/R7 approved
▪ IP67 rated
12VDC 24VDC
0.26A 0.12A
12mA 14.5mA
0.11A 0.05A
O
C
- 1 - July 2022
