Haztec 7-1211-40-8-S Quick Start Manual

7-1211-40-8-S
Flood Barlight
Thank you for purchasing this Haztec product. Before proceeding with installation, it is essential to
read and understand this instruction booklet.
▪ This product must be installed by persons competent in vehicle electrical installations
▪ Care should be taken to ensure that water ingress cannot occur through mounting or
wiring holes
▪ Regularly inspect the product to confirm correct operation
▪ Keep the heatsink fins clean and free of debris in order to maintain air flow
▪ Use only a mixture of soap and water to clean this product
▪ The light becomes hot during continuous operation. DO NOT touch the casing or lens
for at least 30 minutes after switching off
▪ DO NOT stare directly into the light it produces as permanent damage to the eyes
may result
▪ DO NOT allow solvents, fuels, or acetone-based cleaners etc. to contact this product
Basic Operating Specifications:
Supply voltage range:
Power output (lumens):
Beam spread angle:
Operating temperature range:
Fuse rating:
Dimensions (mm):
Connection Instructions:
Wire Connect to
Red Permanent positive [+] via switch & fuse Main Feed
Black Permanent negative [-]
Note: The main feed fuse must be installed within 12" of the power source
M386.1.0
Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
10-30VDC
Raw: 3400 / Effective: 2466
O
15 Spot
O
-40 C to +60
8A
200 (L) x 90 (D) x 70 (H)
T: +44(0)113 202 9115 ∙ info@haztec.uk ∙ www.haztec.uk
▪ Spot beam barlight
▪ 8" (200mm)
▪ 40W single row
▪ 3400lm
▪ 3W CREE LEDs
▪ IP67 rated
▪ 1 year warranty
O
C
Function
Earth/Ground
- 1 - July 2022
