Front Panel 1 x 2*7 Pin header
TPM TPM IC: SLB9670.
Buzzer 1 x Buzzer
Hardware monitor
CPU/System temperature, Voltage monitoring for VCC, 3.3, 5, 12V...
(base on H/W define)
Watchdog Timer Reset; 1 sec.~255 min. and 1 sec. or 1 min. /step by SIO-IT8625
RTC Internal RTC, supports Wake On RTC
DC-IN 9~24V or Type C PD 3.0 (20V 3A/5A, 65/100W)
Power Input
***When plug DC JACK, TYPE-C Disable PD SINK power ferature,TYPE-C Function is USB3.2 GEN2 ALT DP
and Source power 5V@3A****
1 x DC Jack
2 x HDMI connector
1 x Type C
Edge IO 1 x Dual-Stack USB3.0 connectors
1 x Dual-Stack USB2.0 connector
2 x RJ45 connectors, support GbE
1 x Line_out Audio Jack
Expansion slots
1 x 260-pin DDR4 sockets
1 x M.2 Key B with SIM Card Slot
1 x M.2 Key E
1 x M.2 Key M
SATA
1 x SATA3 7pin connector with 1 x 1*4 pin power
Display
1 x 2*3 Pin header for LCD voltage select (3.3V/5V/12V)
1 x 2*20 pin pitch 1.0 box header for LVDS
1 x 1*8 pin pitch 1.25 box header for LVDS Inverter
Audio
1 x 2*5 pin box header for MIC_in, LINE_in, Line_out
1 x 1*4 pin box header for Speaker_out
1 x Buzzer
USB
Onboard pin-header 2 x 2*5 pin header, support 4 x USB2.0
1 x 2*10 pin box pin header, support 2 x USB3.2
Power
1 x ATX 4PIN Connector
Serial Port
4 x 2*5 Box Header for 4 x RS232 (COM1-COM4)
2 x 2*5 Box Header for 2 x RS232/422/485 (COM5-COM6)
6 x 2*3 pin header for COM RI voltage select
Others
1 x 2*5 8-bit DIO pin header
1 x 2*3 pin header for voltage select
1 x 1*4 pin box header for I2C
1 x 1*5 pin box header for SMbus
1 x 2*7 front panel pin header
1 x 1*8 pin wafer LVDS BKLT CONTROL
1 x 1*4 pin header for CPU FAN
1 x 1*3 pin header for system FAN
Windows 10
O.S. support
Linux Ubuntu 20.04
BIOS Support UEFI only
ESD/ EMI Contact with 8Kv, Air with 15Kv, EMI class A
Operation Temp. 0ºC ~ 60ºC
Storage Temp. -40ºC ~ 85ºC
Humidity : 5% ~ 90%
Humidity : 5% ~ 90%
