This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. There is no guarantee that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents here and specially disclaims
any implied warranties of merchantability or fitness for any purpose. Further the vendor reserves the right
to revise this publication and to make changes to the contents here without obligation to notify any party
beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the vendor's approval
in writing.
The content of this user's manual is subject to be changed without notice and we will not be responsible for
any mistakes found in this user's manual. All the brand and product names are trademarks of their respective
companies.

FCC Information and Copyright

Dichiarazione di conformità sintetica
Ai sensi dell'art. 2 comma 3 del D.M. 275 del
30/10/2002
Si dichiara che questo prodotto è conforme
alle normative vigenti e soddisfa i requisiti
essenziali richiesti dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying with the
laws in force and meeting all the essential
requirements as specified by the directives
2004/108/CE, 2006/95/CE and 1999/05/CE
whenever these laws may be applied

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIELK-IHT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar BIELK-IHT

  • Page 1: Fcc Information And Copyright

    FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start .............................3 1.2 Specifications ............................4 1.3 Rear Panel Connectors ...........................5 1.4 Motherboard Layout ..........................6 1.5 SKU & Description ..........................8 2.1 Installing Memory Module ........................9 2.2 Expansion Slots ............................10 2.3 Jumper &...
  • Page 3: Chapter 1: Introduction

    BIELK-IHT User’s Manual Chapter 1: Introduction 1.1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: •  Prepare a dry and stable working environment with sufficient lighting.
  • Page 4: Specifications

    1.2 Specifications Intel® Elkhart Lake J6412 / J6413 Chipset (by BOM option) Intel® Integrated Graphics: eDP – 1 x eDP 1*40 pin connector (by BOM option) Graphic LVDS – 1 x LVDS Dual Channel 2*20pin connector (by BOM option) HDMI – Support 1 x HDMI connector VGA –...
  • Page 5: Rear Panel Connectors

    BIELK-IHT User’s Manual 1.3 Rear Panel Connectors CN1: COM Port1 (D89) Mode RS-422 RS-485 RS-232 Pin Define (1T/1R Full (1T/1R TX Enable (3T/5R) Duplex) Low Active) COM1C_DCD TX(B) (R(B) / T(B)) COM1C_RXD TX(A) (R(A) / T(A)) COM1C_TXD RX(A) COM1C_DTR RX(B)
  • Page 6: Motherboard Layout

    1.4 Motherboard Layout BIELK-IHT »  »  represents the 1st pin. 6 | Chapter 1: Introduction...
  • Page 7 BIELK-IHT User’s Manual Back View Chapter 1: Introduction | 7...
  • Page 8: Sku & Description

    BIELK-IHT R01: eDP / M.2 2242 key B with SATA / Mini-PCIE with PICE+USB2.0 BIELK-IHT R02: LVDS / M.2 3042 / 3052 key B with PCIE+USB3.1 / Mini-PCIE with mSATA BIELK-IHT R03: eDP / M.2 2242 key B with PCIE+USB3.1 / Mini-PCIE with PICE+USB2.0 BIELK-IHT R04: LVDS / M.2 2242 key B with PCIE+USB3.1 / Mini-PCIE with PICE+USB2.0...
  • Page 9: Installing Memory Module

    BIELK-IHT User’s Manual 2.1 Installing Memory Module DIMM1/ DIMM2: DDR4 Memory Module Slot (260pins SO-DIMM) Note »  » If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again. Insert memory module into SO-DIMM socket at backside of motherboard. 1. Hold the SO-DIMM with its notch aligned with the memory socket of the board and insert it at a 30-degree angle into the socket.
  • Page 10: Expansion Slots

    2.2 Expansion Slots CN20: Mini PCI-Express Connector •  The full size mPCIe socket supports mini PCIe module. Installing WiFi Module 1. Insert WiFi module into mini PCIe slot 2. Secure screw to the motherboard »  » Wi-Fi module & screw sold separately. 10 | Chapter 1: Introduction...
  • Page 11: Jumper & Switch Setting

    BIELK-IHT User’s Manual 2.3 Jumper & Switch Setting Jumper Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened...
  • Page 12 JP1/ JP2/ JP3/ JP4/ JP5/ JP6: COM VDD Pin Assignment VCC 5V0 VCC 12V0 Pin 3-5 Short DCD Singal COM1C_DCD_H COM1C_RI_H COM1C_DCD COM1C_RI Pin 4-6 Short RI Singal 12 | Chapter 1: Introduction...
  • Page 13: Headers & Connectors

    BIELK-IHT User’s Manual 2.4 Headers & Connectors JP13: AT Header The connector provides +12V to the CPU power circuit. Pin 1-2 Close: Pin Assignment ATX Mode AT_ATX Pin 2-3 Close: AT Mode CN29: LVDS Pin Assignment Pin Assignment VCCM VCCM...
  • Page 14 CN10: Front Panel & Buzzer This connector includes Power-on, Reset, HDD LED and Power LED connections. It allows user to connect the PC case’s front panel switch functions. Assignment Assignment PWRLED+ EXT SPK- Buzzer PWRLED- N.C. N.C. EXT SPK+ PWRSW- PWRSW+ HW RST- HW RST+...
  • Page 15 BIELK-IHT User’s Manual CN11: Digital I/O Header Pin Assignment CN52: Audio Header Pin Assignment MIC IN LINE IN L LINE IN R SPKOUT L SPKOUT R CN51: SATA Power Connector Pin Signal VCC 5V0 VCC 12V0 SCN2: SIM Slot Pin Assignment...
  • Page 16 CN50: eDP Connector This connector supports 18/24 bit single-channel panels. Pin Signal Signal EMB_HPD EDP_TXN3C EDP_TXP3_C EDP_TXP2_C EDP_TXP2_C EDP_TXN1_C EDP_TXP1_C EDP_TXN0_C EDP_TXP0_C EMB_AUXP EMB_AUXN VSS_EDP_AMOLED 28 VSS_EDP_AMOLED VSS_EDP_AMOLED 30 VSS_EDP_AMOLED EDP_BKLTCTL EDP_BKLTEN VCC_EDP_BKLT VCC_EDP_BKLT VCC_EDP_BKLT VCC_EDP_BKLT 16 | Chapter 1: Introduction...
