2.Construction

(2)
(3)
Name plate
(8)
Pressure gauge port
of downstream Side
IN
(7)
Pressure gauge port
of Upstream Side
No. PART NAME
1 Case
2 Cover
3 Gasket
Element
(For filtration rating
symbol nil )
4
Element
( for filtration rating
symbol x13 )
5 Hex.bolt (M12)
6 Spring washer
7 Plug (1/4)
8 Plug (1/4)
Fig. 1 Construction
Table 1 Part Name
QTY.
AFF75A AFF125A
－
1
－
1
1 AL-33S
1 EC700-003N
1 EC700-X30NX0
－
12
－
12
－
2
－
2
6
(5)
(6)
OUT
(4)
Drain port of downstream side
(Port to discharge separated water,
or oil content, etc, in element.)
(1)
Drain port of upstream side
(Port to discharge removed
water inside case)
MAINTENANCE PART
AFF150A
－ －
－ －
AL-34S
EC800-003N
EC800-X30NX0 EC900-X30NX0
－ －
－ －
－ －
－ －
AFF220A
－
－
AL-35S
EC900-003N
－
－
－
－
