Connecting power

Damage to power supplies
If power supplies do not provide sufficient current, they may be damaged.
Ensure external power supplies or embedded boards provide minimum 1500 mA
for 5 VDC or minimum 600 mA for 12 VDC correspondingly.
1. Ensure all power supplies are disconnected from the mains power.
2. Set the jumpers for Step a and Step b as shown in
3. For power over the FPC connector, continue with
Step c
connector:
or to the
Figure 17: Connections and jumper settings for power supply
4. Connect the power supplies to the mains power.
5. Power and boot the embedded system.
Your vision application is ready for first operation.
Deserializer Board FPD-Link III STP to CSI-2 User Guide V1.0.1
For power over the terminal power connector, connect the Phoenix Contact
MC 1,5/3-ST-3,5 connector as shown in
Step a
or to the
Setting up deserializer boards
NOTICE
Figure 17.
4.
Figure 17 for Step c.
