Note; Shipping Contents; What Else Do You Need - Allied Vision FPD-Link III STP User Manual

Note

Read this document carefully
Learn to use deserializer boards in the most safe and efficient way and avoid
damage to your embedded system.

Shipping contents

The delivery consists of
• Deserializer Board FPD-Link III STP to CSI-2
• 1 preassembled jumper for 5 VDC over FPC (default power mode)
• 1 jumper to enable 12 VDC over terminal connector.
Input power settings
See
Cables are not included
MIPI CSI-2 FPC cables to connect to the host and to the deserializer board and HSD
STP cables to connect the deserializer board to Alvium FP3 STP cameras are not
included.

What else do you need?

This is a selection of helpful downloads:
Download
Camera documentation for installation
and operation:
• Alvium FP3/GM2 User Guide
• Alvium CSI-2 Cameras User Guide
Accessories, such as HSD STP cables,
FPC cables, I/O cables, lenses, and
tripod adapters
SerDes Configurator: Please contact
the Allied Vision Support team at...
Table 1: Downloads for Deserializer Board FPD-Link III STP to CSI-2
Deserializer Board FPD-Link III STP to CSI-2 User Guide V1.0.1
Connecting power on page 42 for jumpers and connections.
Link
www.alliedvision.com/en/support/technical-documentation/
alvium-csi-2-documentation/
www.alliedvision.com/en/products/accessories
www.alliedvision.com/en/about-us/contact-us/
technical-support-repair-/-rma
