Practical tip
Additional information helps to understand or ease handling the camera and
components.
Additional information
Web link or reference to an external source with more information is shown.

Component naming

Components described in this user guide are not defined by common standards.
Therefore, naming must be accurate to avoid misconceptions. Simplified terms are
used in this document to avoid lengthy naming.
Short version used in
this document
Adapter board
Deserializer board
Embedded board
FPC connector
FPC cable
Table 4: Component naming
Deserializer Board FPD-Link III STP to CSI-2 User Guide V1.0.1
Document history and conventions
Long version
Example:
Adapter Board for NVIDIA Jetson Nano and Jetson
Xavier NX DevKit
(adapts Alvium CSI-2 cameras and deserializer boards
to NVIDIA Jetson Nano and Jetson Xavier NX DevKit)
Deserializer Board FPD-Link III STP to CSI-2
Example:
NVIDIA Jetson Xavier NX DevKit
Hirose FH55-22S-0.55SH FPC (flexible printed circuit)
connector
MIPI CSI-2 FPC cable
