HMS Networks Ewon Netbiter EC360W Startup Manual page 17

Technical Data
Product name Netbiter EC310
Max. 32
connected
devices
Baud rates 1200 to 115200 baud
Proxy support
SOCKS (authentication: none, username/password)
WEB (authentication: none, basic)
Mounting
Screw mount or DIN rail using optional mounting kit
92 x 135 x 27 mm
Dimensions (L
x W x H)
Operating -40 to +65 °C
temperature
Storage -45 to +85 °C
temperature
Housing class IP20
Input voltage 9 to 32 VDC
range
24 VDC, 25 W
Recommended
power supply
Power 2.5 W @ 24 VDC
consumption,
typical
Certifications
See
Netbiter EC300 Series Startup Guide
Netbiter EC360
4.5 W @ 24 VDC
www.netbiter.com/support
17 (20)
Netbiter EC360W
2.5W @ 24 VDC
SP3309 2.0 en-US
