Installation
2.4

MODE Button

Factory Reset
Keep the MODE button pressed while powering on to reset the unit to the
factory default settings.
Mobile Signal Strength Indication
Press and release the MODE button to make the top 5 LED indicators indicate
mobile signal strength for 60 seconds.
LED indication
2–5 green LEDs, flashing
1 green LED, flashing
1 orange LED, flashing
1 red LED, flashing
If mobile signal strength is poor
• Make sure that the antenna is correctly installed and of the correct type.
• The antenna should normally be vertically oriented. Signal quality may in
some cases be improved by changing the antenna angle.
• Try moving the unit to another position, or use an external cable for the
antenna to place it in a better position.
Please do not connect to an antenna outdoors.
Netbiter EC300 Series Startup Guide
Meaning
Good to optimum signal
Acceptable signal
Poor signal
No signal or unknown signal
13 (20)
SP3309 2.0 en-US
