Chapter 5 Remote Operation from Command‐Line Interface
The Command Line Interface (CLI) provides the user with a method of controlling the SPDC810N remotely over
the USB interface that is emulating a serial port. A standard terminal program (such as Tera Term) can be used to
send commands to the SPDC810N and receive responses.
The virtual COM port settings should be set up as:
Baud Rate: 115200
Data Bits: 8 bits
Parity: None
Stop Bits: 1 bit
Flow Control: None
The list below shows the list of available commands along with a brief description and syntax. Each command
should be sent with a carriage return, or a line feed, or both at the end of the string.
To signify variables, (variable name, format, range) will be used. {Units} will be called out for reference to the
reader but should not be included in typed commands.
Command/Query
Idn?
le
ld
ldstat
(Pump Power, XXX, 0 to 100)
sloc
scot (Crystal Temp, XX.X, 20.0 to 60.0)
gcot
ontime
ld0curr
getid
gdot
tec0temp
tec1temp
tec1curr
tec1volt
Rev. A, March 14, 2023
Set pump diode operating current as a percent of the
Get pump diode operating temperature set point {°C}
Chapter 5: Remote Operation from Command‐Line Interface
Description
Get identification information
Enable pump diode
Disable pump diode
Get status of pump diode, ON vs OFF
total power {%}
Set crystal operating temperature {°C}
Get crystal operating temperature set point {°C}
Get pump diode uptime {Hr:Min:Sec}
Get current of the laser diode {mA}
Get the serial number of the unit
Get pump diode temperature {°C}
Get crystal temperature {°C}
Get crystal heater current {A}
Get crystal heater voltage {V}
