Insert the air exhaust hose into the window sealing plate. Adjust the opening width
of the window so that it aligns properly with the sealing plate. Length of the sealing
plate is adjustable.
Incorrect installation
• Ensure the exhaust duct remains smooth and properly installed. Incorrect
installation can hinder your appliance's performance.
• A void bending the exhaust duct excessively.
• Make sure there are no obstructions in the duct, ensuring smooth and
uninterrupted airflow.
Warning:
The exhaust duct is designed specifically
for this model.
Do not replace or lengthen it - this could
damage the appliance.
Note:
The maximum length for the exhaust duct is 1,500mm. It's recommended to keep
the duct as short as possible when using the appliance. During installation, keep
the exhaust duct horizontal.
