- Page 1 Documentation | EN KL9300, KL9301 and KL9302 Diode Array Bus Terminals 2024-04-23 | Version: 1.0.0...
-
Page 3: Table Of Contents
Safety instructions .......................... 6 Documentation issue status ...................... 7 Suggestions or proposals for documentation .................. 7 2 Product overview ............................ 8 KL9300 - Introduction ........................ 8 KL9301 - Introduction ........................ 9 KL9302 - Introduction ........................ 10 Technical data .......................... 11 3 Mounting and wiring .......................... - Page 4 Table of contents Version: 1.0.0 KL9300, KL9301 and KL9302...
-
Page 5: Foreword
, XTS and XPlanar are registered trademarks of and licensed by Beckhoff Automation GmbH. Other designations used in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owners. Patent Pending... -
Page 6: Safety Instructions
All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards. -
Page 7: Documentation Issue Status
01 - hardware version 01 Suggestions or proposals for documentation If you have any suggestions or proposals for our documentation, please send us an e-mail stating the documentation title and version number to: documentation@beckhoff.com KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 8: Product Overview
Fig. 1: KL9300 Diode array terminal The KL9300 Bus Terminal contains four potential-free diodes that can be used as free-wheeling or decoupling diodes. Through direct integration into the Bus Terminal assembly, the compact design of the Bus Terminal is retained for the whole application. Wiring is simplified significantly. -
Page 9: Kl9301 - Introduction
The diode array can be used as a free-wheeling or decoupling array. Through direct integration into the Bus Terminal assembly, the compact design of the Bus Terminal is retained for the whole application. Wiring is simplified significantly. KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 10: Kl9302 - Introduction
The diode array can be used as a free-wheeling or decoupling array. Through direct integration into the Bus Terminal assembly, the compact design of the Bus Terminal is retained for the whole application. Wiring is simplified significantly. Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 11: Technical Data
CE, UKCA, cULus, EAC, ATEX [} 24], IECEx [} 25] *) Real applicable approvals/markings see type plate on the side (product marking). Ex markings Standard Marking ATEX II 3 G Ex nA IIC T4 Gc IECEx Ex nA IIC T4 Gc KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 12: Mounting And Wiring
• Each assembly must be terminated at the right hand end with a KL9010 bus end terminal, to ensure the protection class and ESD protection. Fig. 4: Spring contacts of the Beckhoff I/O components Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 13: Installation On Mounting Rails
To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 14: Fig. 6 Disassembling Of Terminal
PE power contact The power contact labeled PE can be used as a protective earth. For safety reasons this contact mates first when plugging together, and can ground short-circuit currents of up to 125 A. Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 15: Disposal
Products marked with a crossed-out wheeled bin shall not be discarded with the normal waste stream. The device is considered as waste electrical and electronic equipment. The national regulations for the disposal of waste electrical and electronic equipment must be observed. KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 16: Installation Instructions For Enhanced Mechanical Load Capacity
• Use countersunk head screws to fasten the mounting rail • The free length between the strain relief and the wire connection should be kept as short as possible. A distance of approx. 10 cm should be maintained to the cable duct. Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 17: Connection
The familiar dimensions of the terminal only had to be changed slightly. The new connector adds about 3 mm. The maximum height of the terminal remains unchanged. KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 18: Fig. 10 High Density Terminals
Ultrasonically “bonded” (ultrasonically welded) conductors Ultrasonically “bonded” conductors It is also possible to connect the Standard and High Density Terminals with ultrasonically “bonded” (ultrasonically welded) conductors. In this case, please note the tables concerning the wire-size width [} 19]! Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 19: Wiring
The cables are released, as usual, using the contact release with the aid of a screwdriver. See the following table for the suitable wire size width. KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 20: Shielding
Wire size width (ultrasonically “bonded" conductors) only 1.5 mm (see notice [} 18]) Wire stripping length 8 ... 9 mm 3.5.3 Shielding Shielding Encoder, analog sensors and actuators should always be connected with shielded, twisted paired wires. Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 21: Kl9300 - Contact Assignment
Mounting and wiring 3.5.4 KL9300 – contact assignment Fig. 12: KL9300 – contact assignment Terminal point, no. Connector for diode 1, anode diode 2, anode diode 3, anode diode 4, anode diode 1, cathode diode 2, cathode diode 3, cathode diode 4, cathode KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 22: Kl9301 - Contact Assignment
Fig. 13: KL9301 – contact assignment Terminal point, no. Connector for diode 1, anode diode 2, anode diode 3, anode diode 4, anode diode 5, anode diode 6, anode diode 7, anode diode 1 to 7, cathode Version: 1.0.0 KL9300, KL9301 and KL9302... -
Page 23: Kl9302 - Contact Assignment
Fig. 14: KL9302 – contact assignment Terminal point, no. Connector for diode 1, cathode diode 2, cathode diode 3, cathode diode 4, cathode diode 5, cathode diode 6, cathode diode 7, cathode diode 1 to 7, anode KL9300, KL9301 and KL9302 Version: 1.0.0... -
Page 24: Atex - Special Conditions (Extended Temperature Range)
80°C at the wire branching points, then cables must be selected whose temperature data correspond to the actual measured temperature values! • Observe the permissible ambient temperature range of -25 to 60°C for the use of Beckhoff fieldbus components with extended temperature range (ET) in potentially explosive areas! •... -
Page 25: Iecex - Special Conditions
• EN 60079-31:2013 (only for certificate no. IECEx DEK 16.0078X Issue 3) Marking Beckhoff fieldbus components that are certified in accordance with IECEx for use in areas subject to an explosion hazard bear the following markings: Marking for fieldbus components of certificate IECEx DEK 16.0078 X... -
Page 26: Continuative Documentation For Atex And Iecex
Pay also attention to the continuative documentation Ex. Protection for Terminal Systems Notes on the use of the Beckhoff terminal systems in hazardous areas according to ATEX and IECEx, that is available for download within the download area of your product on the Beckhoff homepage www.beckhoff.com! -
Page 27: Appendix
Appendix Beckhoff Identification Code (BIC) The Beckhoff Identification Code (BIC) is increasingly being applied to Beckhoff products to uniquely identify the product. The BIC is represented as a Data Matrix Code (DMC, code scheme ECC200), the content is based on the ANSI standard MH10.8.2-2016. -
Page 28: Fig. 16 Example Dmc 1P072222Sbtnk4P562D71Kel1809 Q1 51S678294
Fig. 16: Example DMC 1P072222SBTNk4p562d71KEL1809 Q1 51S678294 An important component of the BIC is the Beckhoff Traceability Number (BTN, position 2). The BTN is a unique serial number consisting of eight characters that will replace all other serial number systems at Beckhoff in the long term (e.g. -
Page 29: Support And Service
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: www.beckhoff.com You will also find further documentation for Beckhoff components there. - Page 30 Fig. 1 KL9300............................Fig. 2 KL9301............................Fig. 3 KL9302............................Fig. 4 Spring contacts of the Beckhoff I/O components ................. Fig. 5 Attaching on mounting rail......................Fig. 6 Disassembling of terminal ......................Fig. 7 Power contact on left side ......................Fig. 8 Standard wiring ..........................
