Wyrestorm EXP-CON-H2-DD Application Programming Interface

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EXP-CON-H2-DD | CON-H2-DD-EARC
Application Programming Interface
Document
V1.0
Revision
Document Date
November 2020
Supported
Refer to
Firmware
Supported Product Firmware/Software
for details.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXP-CON-H2-DD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wyrestorm EXP-CON-H2-DD

Summary of Contents for Wyrestorm EXP-CON-H2-DD

  • Page 1 EXP-CON-H2-DD | CON-H2-DD-EARC Application Programming Interface Document V1.0 Revision Document Date November 2020 Supported Refer to Supported Product Firmware/Software for details. Firmware...

  • Page 2: Table Of Contents

    EDID Settings ......................... 6 General ........................... 7 Contacting Technical Support ....................8 Document Revision History ....................8 Copyright © 2020 WyreStorm Technologies | WyreStorm.com 2 of 8 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) CON-H2-DD API | 201111...

  • Page 3: Overview

    RS-232 Connections The following wiring diagrams show the pinouts for the WyreStorm device. While not shown, connect the TX (transmit) to RX (receive) pins at the control system or PC side of the cable. Most control systems and computers are configured for Digital Terminal Equipment (DTE) where pin 2 is RX and pin 3 is TX This can vary from device to device, refer to the documentation for the connected device for pin functionally to ensure that the connect connections can be made.

  • Page 4: Command Overview

    Please note, most 3rd-party control software will either append these characters automatically or an option to specify them will be present. It is important that the last delimiter character is LF and not CR. Copyright © 2020 WyreStorm Technologies | WyreStorm.com 4 of 8 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 5: Audio Settings

    VOL + Example Response: [SUCCESS] Set all output volume to 75 Volume can only be adjusted for downmixed RCA output Copyright © 2020 WyreStorm Technologies | WyreStorm.com 5 of 8 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 6: Edid Settings

    [SUCCESS] Copy output 01 edid to input 1 HDMIOUT2 is only compatible with CON-H2-DD-EARC Toggle EDID DIP switches to 1111 to enable API control of EDID information Copyright © 2020 WyreStorm Technologies | WyreStorm.com 6 of 8 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 7: General

    RESET When prompted enter “Yes” or “No” to confirm entry. Response Syntax: [SUCCESS] Device properties have been reset to default Copyright © 2020 WyreStorm Technologies | WyreStorm.com 7 of 8 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)

  • Page 8: Contacting Technical Support

    Phone: UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Contact Request: http://wyrestorm.com/contact-tech-support 8. Document Revision History V1.0 – November 2020 Initial Release Copyright © 2020 WyreStorm Technologies | WyreStorm.com 8 of 8 UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) CON-H2-DD API | 201111...
