1x8 4K HDMI2.0 (18Gbps) Splitter with HDCP 2.2
SP-0108-H2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the installation
process.
IMPORTANT! Installation Requirements
• This product was released in multiple versions which contain different
configuration procedures. The differences are identified in the appropriate
sections of this document and versions can be identified by the product
model number sticker. See
Identifying Product
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Install the latest firmware to ensure that all features described in this
document are available during and after installation.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
Basic Wiring Diagram
KEY
HDMI
Power
UHD Display
UHD Display
Copyright © 2017 WyreStorm Technologies |
SP-0108-H2 Quickstart Guide | 171026
Versions.
section for important wiring
12V DC 1A
Power Supply
UHD Display
UHD Display
wyrestorm.com
In The Box
1x SP-0108-H2 Splitter
1x 12V DC 1A Power Supply
1x 3-pin Screw Down Phoenix Connector
2x Mounting Brackets
1x Quickstart Guide (This Document)
Identifying Product Versions
This product was released in multiple versions which contain different
configuration procedures. The differences are identified in the appropriate
sections of this document.
Versions can be identified by a v# after the model number on the product
chassis. Note that version 1 of this product may not contain a v1 after the
product while all versions above version 1 are identified with the version
number.
UHD Source
UHD Display
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Quickstart Guide
UHD Display
UHD Display
UHD Display
