- Page 1 MANUALE D’USO e INSTALLAZIONE Condizionatore d’aria multisplit UNITA’ ESTERNE UNITA’ INTERNE X3MI 105 SH X3I 27 HL X3MI 120SH X3I 35HL X3I 52HL X3I 64HL Leggere attentamente il presente manuale prima di installare e usare il condizionatore e conservarlo per futuri riferimenti.
- Page 2 User Notice The total capacity of the indoor units which runs at the same time can not exceed 150% of that of the outdoor units, otherwise, the cooling (heating) effect of each indoor unit would be poor. Switch the main power on 8 hours before starting the unit, helpful for a successful startup.
- Page 3 The appliance shall be installed in accordance with national wiring regulations. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. This series outdoor units are matched with the free match D.C. inverter Muti-variable air conditioner indoor unit under the same working conditons exported to European Union.
-
Page 4: Table Of Contents
Contents 1 Safety Precautions ..............1 2 Installation Instructions ............2 2.1 Installation Location and Matters Needing Attention ....2 2.2 Installation of the Outdoor Unit ........... 6 2.3 Connection between Indoor and Outdoor Units ......8 2.4 Refrigerant Charging and Trial Running ........11 3 Working Principles of the Unit .......... -
Page 5: Safety Precautions
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit 1 Safety Precautions Please read this manual carefully before using and operating correctly as instructed in this manual. Please especially take notice of the following two symbols： Warning! It indicates improper operation which will lead to human casualty or severe injury. -
Page 6: Installation Instructions
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Caution! Before installation, please check if the power supply corresponds with the requirement specified on the nameplate and also check its security. Before using the unit, please check if the piping and wiring are correct to avoid ... - Page 7 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit 7) Where there is no corrosive gas, heavy dust, salt mist, smog or moisture. (2) How to select the installation location for the outdoor unit 1) The outdoor unit must be installed where the bearing surface is stable and secure enough.
- Page 8 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit damaged it must be replaced by the dedicated one. 6) The earthing should be reliable and the earth wire should be connected to the dedicated device of the building by the professional personnel. Besides, the air switch coupled with the leakage current protection switch must be equipped, which is of enough capacity and of both magnetic and thermal tripping functions in case of the short circuit and overload.
- Page 9 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit X3MI120SH Fig.1 X3MI120SH Fig.2 (5) Noise Precautions 1) The air conditioning unit should be installed where ventilation is in good condition, otherwise the working capability of the unit would be reduced or working noise would be increased.
-
Page 10: Installation Of The Outdoor Unit
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit 3) During the installation, a consideration should be taken that the produced hot air or noise should not affect neighbors or surroundings. 4) Do not stack obstacles near the air outlet of the outdoor unit, otherwise it would reduce the working capability of the unit or increase the working noise. - Page 11 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit (2) Installation of the Outdoor Unit 1) Outline dimension of the outdoor unit. X3MI105SH X3MI120SH Fig.5 2) During the transportation of the outdoor unit, two lifting ropes long enough must be used in four directions and the separation included angle must be less than 40°prevent the center of unit deviating.
-
Page 12: Connection Between Indoor And Outdoor Units
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Fig.6 2.3 Connection between Indoor and Outdoor Units (1) Wiring of the Power Cord CAUTION! A breaker must be installed, capable of cutting off the power supply for the whole system. 1) Open the side plate. 2) Let the power cord go through the rubber ring. - Page 13 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit (3) Allowable Length and Height Fall of the Refrigerant Pipe Table 3 Allowable Length Refrigerant Pipe Total Length(m) L1+L2+L3+ L4 L1+L2+L3+ L4+ L5 Max. Length for Single Unit(m) Outdoor unit and Max. indoor unit installation Indoor unit and...
- Page 14 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Table 5 Moments of Torque for Tightening Screws Wall Thickness（mm） Diameter Moment of Torque Ф6.35mm 15-30(N·m) ≥0.5 Ф9.52mm 30-40(N·m) ≥0.71 Ф12.7mm 45-50(N·m) ≥1 Ф15.9mm 60-65(N·m) ≥1 CAUTION! ①. During the connection of the indoor unit and the refrigerant pipe, never pull any joints of the indoor unit by force, otherwise the capillary pipe or other pipe may crack, which then would result in leakage.
-
Page 15: Refrigerant Charging And Trial Running
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit it enters the wall. During the wrapping, the later circle should cover half of the former one. 3) Fix the wrapped pipe on the wall with clamps. CAUTION! ①. Do not wrap the pipe too tightly, otherwise the insulation effect would be weakened. - Page 16 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Notes： ①. The refrigerant charge mentioned in the table above is not included those charged additionally in the indoor unit and the refrigerant pipe. ②. The amount of the additional refrigerant charge is dependent on the diameter and length of the liquid refrigerant pipe which is decided by the actual yield installation requirement.
- Page 17 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Table 9 Liquid Refrigerant Pipe Serial No. Diameter Ф6.35 Ф6.35 Ф6.35 Ф6.35 Ф9.52 Length The total length of each liquid refrigerant pipe is: e+d+c+b+a=20+20+15+5+5=65m. Thus, the minimum additional refrigerant charge=(65-50)×0.022=0.33kg (Note: no additional refrigerant is needed for the liquid pipe within 50m).
- Page 18 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit The unit may break down or some Are the wiring and the piping correct? components may be burnt out. Has the unit been earthed reliably? There may be a danger of electric shock. Does the wire meet the regulated unit break...
-
Page 19: Working Principles Of The Unit
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit 3 Working Principles of the Unit Schematic Diagram of Free Match Series Inverter Heat Pump Multi VRF System Fig. 11 Schematic Diagram of Free Match Series Inverter Heat Pump Multi VRF System The outdoor and indoor units start to work once the power is switched on. -
Page 20: Parts And Components Of The Unit
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit The refrigerant radiates heat in the heat exchanger of the indoor unit (so do the electric heating devices) and absorb heat in the heat exchanger of the outdoor unit for a heat pump heating cycle so as to achieve the desired heating purpose. -
Page 21: Maintenance
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit 5 Maintenance WARNING! ①. The unit can only be cleaned after the unit is turned off and the main power is cut off, otherwise it would cause an electric shock hazard. ②. Do not dampen the air conditioner, as it would cause an electric shock hazard and never rinse the unit with water in any event. -
Page 22: Troubleshooting
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit 6 Troubleshooting WARNING! ①. In the event of abnormal conditions (like, stinky smell), please shut off the main power supply immediately and then contact the GREE appointed service center, otherwise the continuous abnormal running would damage the air conditioning unit and also would cause electric shock or fire hazard etc.. -
Page 23: Problem Handling
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Note: If the air conditioner still runs abnormally after the above check and handling, please contact the maintenance serviceman at the local appointed service center and also give a description of the error occurred as well as the model of the unit. 6.2 Problem Handling The conditions listed below are not classified into errors. - Page 24 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Table 15(a) Indicating LED Flashing Times Outdoor Wired Error Item Unit 88 Controler Error Type Running Cooling Heating Display Display Display High Pressure Flash Outdoor Protection once Shutdown for Whole Unit Flash System Error Anti-Freeze twice...
- Page 25 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit DC Fan motor Error Outdoor No indoor fan Flash 11 Indoor motor times Compressor phase Flash 12 circuit detection Outdoor times error DC link voltage Flash 20 Outdoor drop error times Zero detection Flash 17 Outdoor circuit error...
- Page 26 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Charging Circuit Flash 17 Drive Error Error times AC Input Voltage Flash 3 Flash 3 Flash 3 Drive Error Anomaly times times times Unit Flash 6 communication Indoor Table 16 times error Unit n indoor pipe midway Flash twice...
- Page 27 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Indoor Unit Water Flash 9 Indoor Full Error times Refrigerant Flash Special Flash once Recovery Mode once Mode Outdoor Ambient Flash 3 Temp Sensor Outdoor times Error Outdoor Mid-Coil Flash 4 Temp Sensor Outdoor times Error...
- Page 28 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Inverter Drive and the Main Controller Radiator Temp Flash 18 Drive Error Sensor Error times Radiator Overheat Flash 19 Drive Error Protection times AC Contactor Drive Error Protection Sensor Connection Drive Error Protection Over Voltage Flash 11...
- Page 29 Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Table 16 Error Error Error Error Description Error Description Error Description Code Code Code Unit A indoor unit Unit B indoor unit pipe Unit C indoor unit pipe pipe outlet outlet temperature outlet temperature temperature sensor sensor error...
-
Page 30: After-Sales Service
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit (Note: Refer to the real products for the exact position of each component.) Once errors are displayed on the controller, please shut off the air conditioning unit and contact the professionally skilled personnel for troubleshooting. 6.4 After-Sales Service If there is any quality or other issue, place contact the GREE after-sales service center. -
Page 31: Performance Parameters
Free Match D.C.inverter Muti-variable Air Conditioner Outdoor Unit Under the unit is under the “Off” status, it is available to switch over the defrosting mode 1 and defrosting mode 2 by pressing the “Mode” and “Blow” buttons simultaneously. 8 Performance Parameters Rated Working Conditions of the Air Conditioning Unit Table 18 Working Temperature Range Indoor side state... - Page 32 REGOLAMENTO (UE) N. 517/2014 - F-GAS L’unità contiene R410A, un gas fluorurato a effetto serra, con potenziale di riscaldamento globale (GWP) = 2087,50. Non disperdere R410A nell’ambiente. X3MI 41 SH - Kg. 1,4 = 2,922 Tonn CO equiv. X3MI 56 SH - Kg.
