Thank you for choosing Air Conditioners, please read this owner's manual carefully before operation
and retain it for future reference. If you have lost the Owner's Manual, please visit www.argoclima.com
X3 Multisplit DCI
Cassette type indoor units
User & Installation Manual
Models:
X3I AS35HL
X3I AS52HL
V 06/2017
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argo X3I AS52HL
Summary of Contents for Argo X3I AS52HL
- Page 1 User & Installation Manual Models: X3I AS35HL X3I AS52HL Thank you for choosing Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference. If you have lost the Owner’s Manual, please visit www.argoclima.com V 06/2017...
- Page 2 User Notice When operating, the entire capacity of the cooperating indoor unit should be not larger than 150% of outdoor unit. Otherwise, it will cause the shortage of cooling (heating) capacity. The total capacity of the indoor units which runs at the same time can not exceed 150% of that of the outdoor units, otherwise, the cooling (heating) effect of each indoor unit would be poor.
- Page 3 Main switch provided by end user: main switch handle should be black or gray, it can be locked in “OFF” position with padlock The main disconnection device s hould be explained in user manual and the height should be recommended at 0.6-1.7m. Over current protection is required(EN 60947-3, EN 60947-2) ...
-
Page 4: Table Of Contents
Contents 1 Safety Information ................. 1 2 Install of The Cassette Type Indoor Unit ..........2 2.1 Schematic diagram of installation spaces ..............2 2.2 Select install location of the indoor unit ............... 2 2.3 Important notice ....................... 3 2.4 Dimension of ceiling opening and location of the hoisting screw (M10) ....4 2.5 Main body of hoisting air conditioner................ -
Page 5: Safety Information
X3 Multisplit Cassette 1 Safety Information Please read this manual carefully before use this unit, and operate it correctly according to the guide in this manual. Please take specially note to the meaning of these two marks: Warning !: This mark means that it may cause casualty or badly heart if the operation is incorrect. -
Page 6: Install Of The Cassette Type Indoor Unit
2 Install of The Cassette Type Indoor Unit 2.1 Schematic diagram of installation spaces X3I AS35HL X3I AS52HL Fig. 2.1 2.2 Select install location of the indoor unit (1) Obstruct should put away from the intake or outlet vent of the indoor unit so that the airflow can be blown though all the room. -
Page 7: Important Notice
X3 Multisplit Cassette (4) The horizontally of the installation place should be guaranteed. (5) Select the place where easy drain condensated coagulated water, and easy connect with outdoor unit. (6) Make sure that there are enough space for care and maintenance. Make sure that the weight between the indoor unit and ground is above 2500mm. -
Page 8: Dimension Of Ceiling Opening And Location Of The Hoisting Screw (M10)
2.4 Dimension of ceiling opening and location of the hoisting screw (M10) Fig. 2.2 Install dimension of mode X3I AS35HL / X3I AS52HL The drilling of holes in the ceiling must be done by the professional personnel. Fig. 2.3 Notes: The dimension for the ceiling openings with * marks can be as large as 610mm. -
Page 9: Main Body Of Hoisting Air Conditioner
X3 Multisplit Cassette 2.5 Main body of hoisting air conditioner (1) The primary step for install the indoor unit. When attach the hoisting stand on hoisting screw, d o use nut and gasket individually at the upper and lower of the hoisting stand to fix it. The use of gasket anchor board can prevent gasket break off. -
Page 10: Connection Of The Refrigerant Pipe
X3 Multisplit Cassette Note ! Please do tighten the nuts and bolts to prevent air conditioner break off. 2.6 Connection of the refrigerant pipe When connect the pipe to the unit or backout it from the unit, please do use both spanner and torque wrench. -
Page 11: Drainage Hose
X3 Multisplit Cassette 2.7 Drainage hose (1) Install the drain hose The diameter of the drain hose should be equal or bigger than the connection pipe’s. (The diameter of polythene pipe: Outer diameter 25mm Surface thickness ≥ 1.5 mm) Drain hose should be short and drooping gradient should at less 1/100 to prevent the formation of air bubble. - Page 12 X3 Multisplit Cassette Drain stepup pi pe note The install height of the drain raising pipe should less than 280mm. The drain raising pipe should form a right angle with the unit, and distance to unit should not beyond 300mm. Fig.
-
Page 13: Electrical Wiring
X3 Multisplit Cassette UI (2) Check the smoothness of drain after installation. Check the drain state by immitting 600cc water slowly from the outlet vent or test hole. Check the drain in the state of refrigerating after installation of the electric circuit. -
Page 14: Install The Panel
X3 Multisplit Cassette Impact tightly by impact fastener after connection and then fit on the electric box (1) and (2). Connect the wiring (communication) through the piping hole of the chassis and the bottom of the appliance upward, then connect the brown wire to the Terminal board “3”, black wire (the communication wire) to the Terminal board “2”... - Page 15 X3 Multisplit Cassette IU careful not to let the swing motor lead wire get caught in the sealing material.) ③. Screw the 4 hexagon head screws under the latches in about 15mm. (The panel would rise) ④. Adjust the panel by turning it toward the direction pointed by the arrow as shown in Fig.
- Page 16 X3 Multisplit Cassette IU Fig. 2.14 ② . If gap still exist between ceiling and decoration panel after tightening the screws, readjust the height of the indoor unit. (As shown in Fig. 2.15). Fig. 2.15 After fi xing, be sure no gap left between the ceiling and the panel. ③...
-
Page 17: Constitutes And Names Of Parts Of Cassette Type Indoor Unit
X3 Multisplit Cassette IU 3 Constitutes and Names of Parts of Cassette Type Indoor Unit X3I AS35HL X3I AS52HL 4 Working Temperature Range Table 4.1 Working Temperature Range Indoor side state Outdoor side stae Dry bulb Wet bulb Dry bulb Wet bulb temp. -
Page 18: Malfunction Debarring
X3 Multisplit Cassette IU 5 Malfunction Debarring Warning! ① . Cut down the main power switch immediately if malfunction (such as smell the burning odor etc.) happened, and then contact service center. If the abnormal state is maintained, the unit may be damaged or electric shock or fire may be happened. -
Page 19: Instruction
X3 Multisplit Cassette IU 5.2 Instruction If problem still cannot found out after above checking, please contact service center and instruct phenomena and model. 5.3 The following circumstance are not malfunction Reason “Malfunction” Start up unit immediately The overload protects switch makes it run Air conditioner after turned off after 3 minutes delay. -
Page 20: Maintenance Method
X3 Multisplit Cassette IU 6 Maintenance Method When air conditioner won’t be used for a long time, please cut o the main power supply of air conditioner. Warning! ① . Do turn off the unit and cut off the main power supply when cleaning the air conditioner, otherwise electric shock or harm may happen. -
Page 21: Clean Air Inlet Grille
X3 Multisplit Cassette IU Note ！ Do not clean the filter by hot water whose temp. is higher than 45 °C to prevent fade or deformation. Do not burn it on fire or the filter would catches fire or deformation. (4) Install air filter Fix the 3 purifiers on filter, install filter on the several bulges on top of air inlet grille, pull the handle behind air inlet grille toward inside to fix filter. -
Page 22: Install And Change Of Air Purifier
X3 Multisplit Cassette IU 6.3 Install and change of air purifier (1) Open air inlet grille (the same the 1st step of Clean Air Filter) (2) Disassembly purifier As shown in fig 21, disassembly air filter, screw out fixing bolts fixed on purifier on filter, then purifier could be disassembly. -
Page 23: Maintenance Before Or After Usage Season
X3 Multisplit Cassette IU Note ！ Do not wipe guide louver powerfully when cleaning, otherwise fluff on surface would fall off. (2) Install guide louver Rotate guide louver slightly could install the protruding edge of both end into grooves on both end of guide louver, and then tighten bolts. 6.5 Maintenance before or after usage season (1) Check before the usage season Check if there is blockage in inlet or outlet vent of air conditioner. - Page 25 X3 Multisplit DCI Wired Remote Controller and Wireless Remote Controller User & Installation Manual Thank you for choosing Commercial Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference.
- Page 26 User Notice ◆ Never install the wired remote controller in the moist circumstance or expose it directly under the sunlight. ◆ Never beat, throw, and frequently disassemble the wired remote controller and the wireless remote controller. ◆ Never operate the wired remote controller and the wireless remote controller with wet hands. Please read the manual carefully before using and installing this product.
- Page 27 Contents Ⅰ Wired Remote Controller ................1 1 Symbols on LCD ................... 1 1.1 Outside View of the Wired Remote Controller ............1 1.2 LCD of the Wired Remote Controller ..............1 2 Buttons ......................2 2.1 Buttons on the Wired Remote Controller .............. 2 2.2 Function of the Buttons ..................
-
Page 28: Ⅰ Wired Remote Controller
X3 Multisplit Wired Remote Controller Ⅰ Wired Remote Controller 1 Symbols on LCD 1.1 Outside View of the Wired Remote Controller AUTO TURBO HOUR SHIELD MEMORY MASTER SAVE QUIET E-HEATER BLOW Enter/Cancel Mode Enter/cancel Function Timer On/Off Fig.1 Outside View of the Wired Remote Controller 1.2 LCD of the Wired Remote Controller 4 5 6 AUTOT URBO... -
Page 29: Buttons
X3 Multisplit Wired Remote Controller Table 1 Symbols Description Swing function. Sleep function (Only sleep 1). Running modes of the indoor unit (Cooling, Dry, Fan and Heating). Defrosting function for the outdoor unit. Gate-control function (this function is yet unavailable for this unit). Lock function. -
Page 30: Function Of The Buttons
X3 Multisplit Wired Remote Controller 2.2 Function of the Buttons Table 2 Name Function Enter/Cancel Function selection and cancellation. ▲ ① Running temperature setting of the indoor unit, range:16 ～ 30℃ . ② Timer setting, range:0.5-24 hr. ▼ Setting of the high/middle/low/auto fan speed. Mode Setting of the Cooling/Heating/Fan/Dry/Auto mode of the indoor unit. -
Page 31: Operation Instructions
X3 Multisplit Wired Remote Controller 3 Operation Instructions 3.1 On/Off Press On/Off to turn on the unit and turn it off by another press. Note: The state shown in Fig.4 indicates the “Off” state of the unit after power on. The state shown in Fig.5 indicates the “On”... -
Page 32: Fan Setting
X3 Multisplit Wired Remote Controller Fig.6 3.4 Fan Setting Under the “On”/”Off” state of the unit, press Fan and then fan speed of the indoor unit will change circularly as shown in Fig.7. Middle High AUTO Enter/Cancel Mode Function Timer On/Off Fig.7 3.5 Timer Setting... - Page 33 X3 Multisplit Wired Remote Controller Fig. 8 Timer off Setting under the “On” State of the Unit Timer range: 0.5-24hr. Every press of ▲or ▼ will make the set time increased or decreased by 0.5hr. If either of them is pressed continuously, the set time will increase/ decrease by 0.5hr every 0.5s.
-
Page 34: Swing Setting
X3 Multisplit Wired Remote Controller 3.6 Swing Setting Swing On: Press Function under on state of the unit to activate the swing function. In this case, Swing Off: When the Swing function is on, press Function to enter the Swing setting interface, with blinking. -
Page 35: Sleep Setting
X3 Multisplit Wired Remote Controller 3.7 Sleep Setting Sleep on: Press Function under on state of the unit till the unit enters the Sleep setting Sleep off: When the Sleep function is activated, press Function to enter the Sleep setting interface. -
Page 36: Turbo Setting
X3 Multisplit Wired Remote Controller 3.8 Turbo Setting Turbo function: The unit at the high fan speed can realize quick cooling or heating so that the room temperature can quickly approach the setting value. In the Cooling or Heating mode, press Function till the unit enters the Turbo setting interface When the Turbo function is activated, press Function to enter the Turbo setting interface and then press Enter/Cancel to cancel this function. -
Page 37: E-Heater Setting
X3 Multisplit Wired Remote Controller 3.9 E-heater Setting E-heater (auxiliary electric heating function): In the Heating mode, E-heater is allowed to be Once the wired remote controller or the remote controller enters the Heating mode, this function will be turned on automatically. Press Function in the Heating mode to enter the E-heater setting interface and then press Enter/Cancel to cancel this function. -
Page 38: Blow Setting
X3 Multisplit Wired Remote Controller 3.10 Blow Setting Blow function: After the unit is turned off, the water in evaporator of indoor unit will be automatically evaporated to avoid mildew. In the Cooling or Dry mode, press Function till the unit enters the Blow setting interface and then press Enter/Cancel to active this function. -
Page 39: Other Functions
X3 Multisplit Wired Remote Controller 3.11 Other Functions (1). Lock Upon startup of the unit without malfunction or under the “Off” state of the unit, press ▲ and ▼ at the same time for 5s till the wired remote controller enters the Lock function. In this case, LCD displays . -
Page 40: Installation And Dismantlement
X3 Multisplit Wired Remote Controller 4 Installation and Dismantlement 4.1 Connection of the Signal Line of the Wired Remote Controller ● Open the cover of the electric control box of the indoor unit. ● Let the single line of the wired remote controller through the rubber ring. ●... - Page 41 X3 Multisplit Wired Remote Controller Fig.15 Fig.15 shows the installation steps of the wired remote controller, but there are some issues that need your attention. (1). Prior to the installation, please firstly cut off the power supply of the wire buried in the installation hole, that is, no operation is allowed with electricity during the whole installation.
-
Page 42: Dismantlement Of The Wired Remote Controller
X3 Multisplit Wired Remote Controller cord and connection lines between the indoor and outdoor unit, with a minimum interval of 20cm, otherwise the communication of the unit will probably work abnormally. If the air conditioning unit is installed where is vulnerable to electromagnetic interference, ②... - Page 43 X3 Multisplit Wired Remote Controller Table 4 Meaning of Each Error Error Error Error Error Code Code Return air temperature sensor open/short Drive board communication error circuited evaporator temperature sensor open/short Compressor overheating protection circuited Indoor unit liquid valve temperature sensor Indoor and outdoor units unmatched open/short circuited Indoor gas valve temperature sensor open/...
-
Page 44: Ⅱ Wireless Remote Controller
X3 Multisplit Wireless Remote Controller Ⅱ Wireless Remote Controller Notes: Be sure that there are no obstructions between the receiver and the remote controller; ① . Do not drop or throw the remote controller; ② . Do not let any liquid into the remote controller and expose the remote controller to direct ③... - Page 45 X3 Multisplit Wireless Remote Controller 3) SLEEP Sleep On and Sleep Off can be selected by pressing this button. After powered on, the default is Sleep Off. After the unit is turned off, the Sleep function is canceled. When the sleep function is set already, the symbol will be displayed.
-
Page 46: Guide For General Operation
X3 Multisplit Wireless Remote Controller temperature, or indoor ambient temperature. When the indoor unit is powered on, the indoor set temperature will be displayed, while if the status is changed to , the indoor ambient temperature will be displayed. However, the indoor set temperature will be displayed again when the controller receives other remote controls signals. -
Page 47: Guide For Optional Operation
X3 Multisplit Wireless Remote Controller d. Press FAN to set the fan speed, Auto, Low, Medium, or High. e. Press to select the swing angle. 3 Guide for Optional Operation a. About X-FAN This function indicates that moisture in the evaporator of the indoor unit will be dried after the unit is stopped to avoid mould.
