Summary of Contents for Argo X3I ECO AS45HL
-
Page 2: Table Of Contents
Contents 1 Safety Precautions ..................1 2 Outline of the Unit and Main Parts..............3 3 Operation of remote controller................. 4 3.1 Buttons on remote controller ..............4 3.2 Introduction for icons on display screen............. 4 3.3 Introduction for buttons on remote controller..........5 3.4 Function introduction for combination buttons.......... - Page 3 Please read this operating manual carefully before operating the unit. to the material objects for reference. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates leads to explosion . It can Compared to common refrigerants, R32 is a nonpolluting refrigerant with no lower.
-
Page 4: Safety Precautions
DC Inverter Cassette Type Unit 1 Safety Precautions This mark indicates procedures which, if improperly performed, might lead to the WARNING! death or serious injury of the user. This mark indicates procedures which, if improperly performed, might possibly result CAUTION! in personal harm to the user, or damage to property. - Page 5 (14). During installation, attach the refrigerant piping securely before running the compressor. If the compressor is not attached and the stop valve is open during pump-down, air will be sucked in when the compressor is run, causing abnormal pressure in the freezer cycle which will lead to breakage and even injury.
-
Page 6: Outline Of The Unit And Main Parts
2 Outline of the Unit and Main Parts Indoor 1. Drainage device 2. Drainage pipe Outdoor 4. Connection pipe Air inlet 5. Wired Controller 6. Wireless Controller 7. Big handle 8. Liquid Pipe 9. Gas pipe 10. Drainage pipe Air outlet 11. -
Page 7: Operation Of Remote Controller
3 Operation of remote controller 3.1 Buttons on remote controller ON/OFF button MODE button +/- button FAN button I FEEL button button button button CLOCK button TIMER ON/TIMER OFF button X-FAN button Note: X-FAN is the same with BLOW TEMP button TURBO button SLEEP button LIGHT button... - Page 8 Note: Note:...
- Page 9 +/- button ture 1 Holding "+" or "-" button, 2s later, set temperature on remote controller will tor on indoor unit will change accordingly. (Temperature can’t be adjusted under auto mode) TIMER ON, TIMER OFF or CLOCK, press "+" or "-" button to adjust time.
- Page 10 button Press this button can select up&down swing angle. Fan blow angle can be selected circularly as below: no display (horizontal louvers stops at current position) . Horizontal louver will automatically swing up & down at maximum angle. required angle, release the button. Note: air conditioner will blow fan automatically.
- Page 11 started up, press "TIMER ON" button to cancel it. TIMER OFF button "TIMER OFF" button can set the time for timer off. After pressing this button," " icon disappears and the word "OFF" on remote controller blinks. Press "+" or "-" button to adjust TIMER OFF setting.
-
Page 12: Function Introduction For Combination Buttons
r, temperature indicator on indoor unit displays outdoor ambient temperature. Note: Outdoor temperature display is not available for some models. At that time, indoor unit receives " "signal, while it displays indoor set temperature. ’s defaulted to display set temperature when turning on the unit.There is no display in the remote controller. -
Page 13: Operation Guide
3.5 Operation guide After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "+" or "-" button to set your required temperature. (Temperature can’t be adjusted under auto mode). -
Page 14: Preparative For Installation
Preparative for Installation .1 Standard Accessory Parts The standard accessory parts listed below are furnished and should be used as required. Table 1 Indoor Unit Accessories Name Appearance Q'ty Usage To connect with the hard PVC drain Drain Hose pipe Nut with Washer unit. -
Page 15: Connection Pipe Requirement
.2.1 Indoor Unit Select an installation site where the following conditions are fulfilled and that meets your customer’s approval. (1). Obstruct should be put away from the intake or outlet vent of the indoor unit so that the (2). Make sure that the installation meets the requirement of the schematic diagram of installation spaces. -
Page 16: Electrical Requirement
Table 3 Size of Fitting Max. Max. Height Drainage Item Pipe(Inch) Pipe Difference between pipe(Outer Length Indoor Unit and Diameter × wall Model Liquid Outdoor Unit (m) thickness) (mm) The connection pipe should be insulated with proper water-proof insulating material. The pipe wall thickness shall be 0.5-1.0mm and the pipe wall shall be able to withstand the pressure of 6.0 MPa. -
Page 17: Installation Of The Unit
Installation of the Unit .1 Installation of the Indoor Unit .1.1 Indoor unit dimension For the units: 12-18k Table Item Model GKH(12)BB-K6DNA3A/I GKH(18)BB-K6DNA3A/I... - Page 18 .1.2 Installing the Main Body Unit Fig. (1). Install the hoisting stand on the hoisting screw by using nuts and gaskets at both the upper and lower sides of the hoisting stand. To prevent the gasket from breaking off, a gasket anchor board can be helpful.
-
Page 19: Installation Of The Connection Pipe
.1.4 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below. Horizontal tester Fig.8 .2 Installation of the Connection Pipe .2.1 Flare Processing (1). Cut the connection pipe with the pipe cutter and remove the burrs. (2). - Page 20 .2.2 Bending Pipes (1). The pipes are shaped by your hands. Be careful not to collapse them. Fig.10 (2). Do not bend the pipes in an angle more than 90°. Pipe Heat insulating (3). When pipes are repeatedly bent or stretched, the material pipe will Cutter...
- Page 21 hand tight and then tighten it with the spanner. Refer to Table to check if the wrench has been tightened properly (too tight would mangle the nut and lead to leakage). Examine the connection pipe to see if it leaks, then take the treatment of heat insulation, as shown in the Fig.12.
- Page 22 .2.4 Connecting the Pipe at the Outdoor Side Unit connector. The tightening method is the same as that as at the indoor side. .2.5 Checking the Pipe Connections for Gas Leaking For both indoor and outdoor unit side, check the joints for gas leaking by the use of a gas leakage detector without fail when the pipes Fig.13...
-
Page 23: Vacuum And Gas Leakage Inspection
If the outdoor unit is installed higher than the indoor unit (See Fig.16) (1). Taping should be done from lower to the upper part. (2). All pipes are bound and taped together and also should be trapped to prevent water from returning to the room. (3). - Page 24 (7). Slightly open the liquid valve and let some refrigerant go to the connection pipe to balance the pressure inside and outside of the connection pipe, so that air will not come into the connection pipe when removing the hose. Note that the gas and liquid valve can be opened fully only after the manifold valve assembly is removed.
-
Page 25: Installation Of The Drain Hose
5.4 Installation of the Drain Hose 5 .4.1 Installationof Drain Piping (1). Keep piping as short as possible and slope it downwards at a gradient of at least 1/100 so that air may not remain trapped inside the pipe. (2). Keep pipe size equal to or greater than that of the connecting pipe. (3). - Page 26 (3). When unifying multiple drain pipes, install the pipes as Fig.20. Select converging drain pipes whose gauge is suitable for the operating capacity of the unit.(take the cassette type unit for example) T-joint converging drain pipes T-joint converging drain pipes Fig.20 (4).
- Page 27 3-way connection Connection of drain elbow of drainage pipe joint Connection of horizontal pipe Fig.24 Fig.25 Fig.26 .4.3 Precautions When Doing Riser Piping Work (1). Make sure that heat insulation work is executed on the following 2 spots to prevent any possible water leakage due to dew condensation.
-
Page 28: The Panel Installation
.4.4 Testing of Drain Piping Shown in the Fig.29, Add approximately 1liter of water slowly into the drain pan and check Drain hose Test hole cover Drain vent for repair use (plastic stopper is included) (drain the water in waterspoit by this outlet vent) Test hole <Immiting water from the rest hole>... - Page 29 (3). If gap still exists between ceiling and decoration panel after tightening the screws, readjust the height of the indoor unit. (Fig.32) Fig.32 (4). Fig.33 Fig.33 .5.2 Installing the Panel (1). (2). Latch other two hooks. (3). Tighten four hexagonal screws under the latches about 15mm. (4).
-
Page 30: Electrical Wiring
Fig.34 5.6 Electrical Wiring 5.6.1 Wiring Precautions WARNING! Before obtaining access to terminals, all supply circuits must be disconnected. The rated voltage of the unit is as shown as Table 4 Before turning on, verify that the voltage is within the 198~264V range(for single phrase unit) or 342~457V range (for three-phrase unit). - Page 31 CAUTION! The power source capacity must be the sum of the air conditioner current and the current of other capacity. raise the voltage. 5.6.2 Electrical Wiring (1). For solid core wiring (Fig.35) 1). Cut the wire end with a wire cutter or wire-cutting pliers, then strip the insulation about 25 mm (15/16") .
- Page 32 After passing the connection cord fasten it with the cord clamp.(Fig.37) WARNING! Before starting work, check that power is not being supplied to the indoor unit and outdoor unit. Match the terminal block numbers and connection cord colors with those of the indoor unit side. Erroneous wiring may cause burning of the electric parts.
- Page 33 (5). Electric wiring of indoor unit side Remove the electric box cover from the electric box sub-assy and then connect the wire. Power supply terminal board Seal here to avoid leakage Fig.39...
- Page 34 V 12/18...
-
Page 35: Installation Of Controllers
CAUTION! Tighten the power cord respectively on the terminal boards with If the power supply are wired incorrectly, the air conditioner may be damaged. Connect the indoor unit connection cord properly based on the corresponding marks as shown in Fig.38. Ground both the indoor and outdoor units by attaching a ground wire. - Page 36 Table 8 Number Error code Error Compressor high pressure protection Indoor anti-freeze protection Compressor low pressure protection, refrigerant lack protection and refrigerant colleting mode Compressor high discharge temperature protection AC over-current protection Communication error Mode conflict Anti-high temperature protection Full water protection Indoor ambient temperature sensor is open/short circuited Indoor evaporator temperature sensor is open/short circuited Outdoor ambient temperature sensor is open/short circuited...
- Page 37 (2). Instructions to the Error Indicating Lamps on the Panel of the Cassette Type Unit. Receiver "88" Dispaly "Auto" Button Power Timer "Test" Button Indicating Lamp Indicating Lamp Fig.40 Power and ON/OFF Indicating Lamp: It goes red when the unit is powered on while it goes white when the unit is started. Timer Indicating Lamp: Timer indicator on indoor unit will be on when timer ON is set under off status and timer OFF is set under on status.
-
Page 38: Troubleshooting And Maintenance
Troubleshooting and Maintenance .1 Troubleshooting following points before repair: Table Failure Possible Reasons The power supply is not connected. Electrical leakage of air-conditioning unit causes tripping of the leakage The unit cannot be started. switch. The operating keys are locked. The control loop has failure. -
Page 39: Routine Maintenance
.2 Routine Maintenance Before accessing to terminal devices, all power supply circuits must be disconnected. Notes: the unit. Do not clean the unit with gasolene, benzene, thinner, polishing powder or liquid insecticide, otherwise it would cause discoloration and deformation of the unit. Increase the frequency of cleaning if the unit is installed in a room where the air is extremely (2). - Page 40 2. Disassemble the air inlet grille Open the air inlet grille at 45°, raise it and remove the grille. Filter screen Filtering element Support Bolt up, wash it by warm water meld with the Note: Never use hot water over 45°C in case of color fading or turning yellow.
- Page 41 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32 into the atmosphere. www.argoclima.com...
