Expansion Modules

Catalog Input
number power
24V dc
NX7-28EDR power
supply
24V dc
NX7-28EDT power
supply

Programming Software

Catalog
Number
Allows you to perform the following tasks on a
remote computer:
• PLC program editing and monitoring
• file management
• program backup
WinGPC 3.8
• online editing (instruction change only)
(Windows)
• error and status check-up
• network status check-up
• I/O mapping
• time chart monitoring

Cables

Catalog
number
NX_CBLCPU02 PLC to PC communication (WinGPC)
cable length: 2 m
NX_CBLCPU05 Same functions with NX_CBLCPU2
cable length: 5 m
8
I/O specifications
16-point dc input
12-point relay output
16-point dc input
12-point transistor output
Specifications
Specifications
Remarks
• 16-point 24V dc input
• 12-point relay output
2A per point
• 16-point 24V dc input
• 12-point transistor
output
4A per point
Remarks
For Windows 95/98/
2000/NT
Remarks
Communication cable
for both RS232C and
RS485
