Mounting Dimensions
10-, 14-, 20- and 28-point
controllers
100 mm
Φ 4.2
9.5
81.0 mm
(3.19 in)
87.0 mm
(3.43 in)
9.5
1.5
3.0
Mounting Spacing
Allow at least 50 mm (2 in.) space on all sides of the controller for adequate
ventilation, as shown below.
Left
12
40- and 48-point controllers
126.0 mm
90 mm
(4.96 in)
9.5
1.5
3.0
Top
Bottom
unit: mm
146.0 mm
Φ 4.2
9.5
87.0 mm
(3.43 in)
Right
90 mm
