Overview

Base Controllers

Catalog Input
number power
NX7-28ADR
100 to
NX7-28ADT
240V ac
power
NX7-48ADR
supply
NX7-48ADT
NX7-28DDR
NX7-28DDT
24V dc
power
supply
NX7-48DDR
NX7-48DDT
NX7s-10ADR
NX7s-10ADT
NX7s-14ADR
NX7s-14ADT
NX7s-20ADR
100 to
NX7s-20ADT
240V ac
power
NX7s-28ADR
supply
NX7s-28ADT
NX7s-40ADR
NX7s-40ADT
NX7s-48ADR
NX7s-48ADT
I/O specifications
16-point dc input
12-point relay output
16-point dc input
12-point transistor output
28-point dc input
20-point relay output
28-point dc input
20-point transistor output
16-point dc input
12-point relay output
16-point dc input
12-point transistor output
28-point dc input
20-point relay output
28-point dc input
20-point transistor output
6-point dc input
4-point relay output
6-point dc input
4-point transistor output
8-point dc input
6-point relay output
8-point dc input
6-point transistor output
12-point dc input
8-point relay output
12-point dc input
8-point transistor output
16-point dc input
12-point relay output
16-point dc input
12-point transistor output
24-point dc input
16-point relay output
24-point dc input
16-point transistor output
28-point dc input
20-point relay output
28-point dc input
20-point transistor output
Remarks
• Built-in 9k steps memory
• Several µs per step
processing speed
• Built-in 1 HSC input
channel
• Built-in 2 pulse output
channels built in
• 2 communication ports
• Expandable to up to two
expansion modules
(NOTE: Some relevant
contacts are unavailable
when HSC input or pulse
output channels are used.)
• Built-in 2k steps memory
• Several µs per step
processing speed
• Built-in 1 HSC input
channel
• Built-in 2 pulse output
channels built in
• 2 communication ports
COM1: RS232C
COM2: RS485
• Expansion unsupported
(NOTE: Some relevant
contacts are unavailable
when HSC input or pulse
output channels are used.)
