Transistor Output
Item
Catalog number
Output points
Insulation method
Rated load voltage
Load voltage range
Polarity
Max. load current
Max. inrush current
Off state leak current
Off → On
Response
time
On → Off
Internal current consumption
(5V)
Common method
Status display
External connection method
Recommended wire size
26
Transistor output controllers
NX7-28xxT
NX7s-10xxT
NX7s-14xxT
NX7s-20xxT
NX7s-28xxT
12 points for NX7-28xxT
4 points for NX7s-10xxT
6 points for NX7s-14xxT
8 points for NX7s-20xxT
Photocoupler
12 to 24V dc
10 to 30V dc
- common (Sink type, NPN)
0.4A per point, 1.0A per common
3A, 10 ms or less
100 A or less
1 ms or less
1 ms or less
80 mA or less
1, 4, and 6 points per common
LED
Terminal block (M3.0), terminal width: 6.4 mm or less
2
0.5 to 1.25 mm
NX7-48xxT
NX7s-40xxT
NX7s-48xxT
20 points for NX7-28xxT
16 points for NX7s-20xxT
