Chapter 2 - Specifications; Mtcdt-L4G1 Specifications - Multitech Conduit Cat 4 Hardware Manual

SPECIFICATIONS
Chapter 2 – Specifications

MTCDT-L4G1 Specifications

Category
General
Performance
TCP/IP Functions
Frequency Bands (MHz)
Speed
Data Speed
Physical Description
Dimensions
Weight
Connectors
8
Description
3GPP Rel. 11 LTE
UMTS/HSPA+
GSM/GPRS/EDGE
USB Interface is CDC-ACM compliant
FTP, SMTP, SSL, TCP, UDP
LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/
B19/B20/B25/B26/B28
LTE TDD: B38/B39/B40/B41
WCDMA: B1/B2/B4/B5/B6/B8/B19
GSM: B2/B3/B5/B8
LTE FDD: Max 150 Mbps (DL)/Max 50 Mbps (UL)
LTE TDD: Max 130 Mbps (DL)/Max 35 Mbps (UL)
UMTS: DC-HSDPA: Max 42 Mbps (DL)
UMTS: HSUPA: Max 5.76 Mbps (UL)
UMTS: WCDMA: Max 384 Kbps (DL)/Max 384 Kbps (UL)
GSM: EDGE: Max 296 Kbps (DL)/Max 236.8 Kbps (UL)
GSM: GPRS: Max 107 Kbps (DL)/Max 85.6 Kbps (UL)
See the drawing in Dimensions.
15.6 oz. (442.25 grams) with no accessory cards installed
®
Conduit Cat 4 MTCDT-L4G1 Hardware Guide
