ENJOY SMART LIFE
Installation Manual
Model:E18PRO/E13PRO
Thank you for choosing our products. Please read the instructions carefully before
installation and keep it available for future maintenance or reference.
E-mail:service@eplo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E18PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EPLO E18PRO

  • Page 1 ENJOY SMART LIFE Installation Manual Model:E18PRO/E13PRO Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. E-mail:service@eplo.com...
  • Page 2: Table Of Contents

    Content Safety instructions Technical specification List of materials Technical drawing Parts identification Toilet installation Preparation Lid auto open/close Foot sensor Maintenance 1. Main unit care and maintenance 2. Spray nozzle maintenance and care 3. Filter maintenance Emergency troubleshooting 1. Power and water failure 2.
  • Page 3 IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
  • Page 4 Keep the cord away from heated surfaces. Never use while sleeping or drowsy. Never drop or insert any object into any opening or hose. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered. Connect this product to a properly grounded outlet only.
  • Page 5: Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Indicates that failure to follow the instruction may cause body CAUTION – injury or property damage. Do not install or use the product in wet places as steam room etc. It is recommended to use water-proof electrical outlet which should be installed in a place where is not easily to get wet.
  • Page 6 11. L'exposition directe au soleil est interdite. 12. Utilisez uniquement de l'eau du robinet ou de l'eau potable, sinon vous risquez de causer des éraflures. 13. Ne raccordez pas l'alimentation en eau à la sortie de l'appareil de chauffage. S'assurer que la température de l'eau d'entrée est comprise entre 3~35 /37.4~95 .
  • Page 7: Technical Specification

    Technical specification Rated voltage 110V-120V, 50/60Hz Rated power 875W Main Unit Water proof IPX4 Power cord length About 1.5m Flush volume 1.6/1.1Gpf, 6.0L(full flush)/4.1L(half flush) Flushing mode Siphonic jet Rough-in 305mm Toilet Outlet outside diameter ≤100mm Drainage method S-trap Water pressure range 0.08MPA-0.8MPa (static pressure) Heating mode Instant...
  • Page 8 Deodorization Deodorization method Diatom Deodorization Surface temperature 6-level adjustment Heating power Open and close device Quiet soft-close Heated seat After 10 minutes of use, the seat Burn protection temperature will automatically drop slowly to a low level Seat sensor, Temperature sensor, Thermal Safety device fuse, Thermostat, Leakage protection plug Night light assembly...
  • Page 9: List Of Materials

    Remote Control Components Sealing Flange Installation Cardboard ENJOY SMART LIFE Installation Manual Model:EP-E18PRO Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. E-mail:service@eploglobal.com Braided Hose Installation Manual...
  • Page 10: Technical Drawing

    Technical drawing 690mm 1. The drawing is for reference only, and we reserve the right to modify the product appearance. 2. Product appearance is subject to change in kind.
  • Page 11: Parts Identification

    Parts identification Left side Bumper Seat Knob Ceramic toilet Right side Dryer shield Rear washing Remote Front control sensor washing Spray nozzle Touch the sensing area with foot...
  • Page 12: Toilet Installation

    Toilet installation 1. Installation of angle valve 3. Hose Draw drain outlet centerline on the floor. Connect the water inlet and angle valve Install angle valve at proper position on of the toilet with the matching hose and the wall according to the dimension of tighten it.
  • Page 13 4. Mounting bracket installation 6. Screw installation Assemble the mounting bracket with Put the screw through the fixing sleeve bolts and then install them to the and then install it through the holes (on both sides of the toilet ceramic) to the pre-installed flange plate on the ground mounting bracket on the ground.
  • Page 14: Preparation

    Preparation 1. Turn on the angle valve Check the threaded connection for leaks to ensure complete sealing. Turn the angle valve counterclockwise to the full open position. (Note: The angle valve opens with a large torque for the first time.) Angle valve 2.
  • Page 15: Lid Auto Open/Close

    Lid auto open/close Only for the product with lid auto opening/closing function. If the auto lid open/close function is disabled, please use the remote control to enable this function. 1. Approaching the toilet When user enters the sensing range, the seat lid opens automatically.
  • Page 16: Foot Sensor

    Foot sensor If the model you purchased is with foot sensor, 1. When the lid and seat are both closed, touch the sensing area with foot to open the lid. Seat 2. When the lid is open and seat closed, touch the sensing area with foot to open the seat. Seat 3.
  • Page 17: Maintenance

    Maintenance Main unit care and maintenance 3. Use only a soft cloth or soft brush to clean. Do not pull or push the wand, to 1. Shut off power supply before doing avoid damage. maintenance. 2. Use only a soft, damp cloth to clean. Avoid using harsh chemicals.
  • Page 18: Emergency Troubleshooting

    Emergency troubleshooting Power and water failure Product unused for a period of time Put around 2.1Gal (8L) water into a barrel When the product is left unused for a and flush the ceramic bowl. long time, especially in cold weather, it is highly recommended to drain the Note: Avoid water spilling from bowl.
  • Page 19: Description Of The Knob Function

    Description of the knob function 1. When seated, turn the knob clockwise to start front washing function, and turn counterclockwise to start rear washing function. Rear and front washing function will automatically enter into the drying function after completion. (Note: default water pressure, water temperature, air temperature, seat temperature, wand position are intermediate.)...
  • Page 20: Top Panel Indicator Light Instruction

    Top Panel Indicator Light Instruction Temperature display ①Temperature display: When the water temperature Divider line indicator light is on, it displays water temperature, when the seat temperature indicator light is on, it Seat temperature displays the seat temperature, and when in neutral, it displays "--"...
  • Page 21: Troubleshooting Guide

    Troubleshooting guide Problem Cause Solution Water supply hose is kinked. Straighten the hose to remove the kink. Angle valve is not fully Poor flushing Turn on the angle valve fully. turned on. Filter is dirty. Clean the filter. Angle valve is shut off. Turn on the angle valve.
  • Page 22 Problem Cause Solution Power off Turn on the power. The seat switch will not turn on unless the user is seated Sit back on the toilet seat. properly. Stuck due to impurities Remove impurities. Spray rod does not operate or Press the "STOP"...
  • Page 23 Problem Cause Solution Night light Night light function is "OFF". Set to "ON". does not work The positive and negative direction of the batteries is Re-load batteries. Remote control incorrect. does not work Batteries have expired Load new batteries. The drying feature stops automatically after about 5 minutes of continuous use.
  • Page 24 The picture of product may not be entirely consistent with actual appearance and color because of product improvements, please in kind prevail. ASVFAF0401010A-1.1...
