ENJOY SMART LIFE Installation Manual Model:EP-U8PRO/U9PRO Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. E-mail:service@eplo.com...
Content Safety instructions Technical specification List of materials Technical drawing FCC Statement IC Statement Parts identification Toilet installation Preparation Auto open/close lid Foot sensor Maintenance 1. Main unit care and maintenance 2. Filter maintenance 3. Spray nozzle care and maintenance Emergency troubleshooting 1.
Page 3
IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Page 4
Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the product to a service center for examination and repair. Keep the cord away from heated surfaces.
IMPORTANT SAFETY INSTRUCTIONS Indicates that failure to follow the instruction may cause CAUTION – body injury or property damage. Do not install or use the product in wet places as steam room etc. It is recommended to use water-proof electrical outlet which should be installed in a place where is not easily to get wet.
Page 6
10. N'utilisez pas de produits chimiques agressifs ou de brosses pour nettoyer ce produit. 11. L'exposition directe au soleil est interdite. 12. Utilisez uniquement de l'eau du robinet ou de l'eau potable, sinon vous risquez de causer des éraflures. 13. Ne raccordez pas l'alimentation en eau à la sortie de l'appareil de chauffage. S'assurer que la température de l'eau d'entrée est comprise entre 3~35 /37.4~95 .
Technical specification Rated voltage 110-120V,50-60Hz Rated power 875W Main Unit Water proof IPX4 Power cord length About 1.5m Flush volume 1.6/1.1Gpf, 6.0L(full flush)/4.1L(half flush) Flushing mode Siphonic jet Rough-in 12 inches (305mm) Toilet Outlet outside diameter ≤ 3.9 inches (≤ 100mm) Drainage method S-trap Minimum water pressure 0.08MPa, Maximum...
Page 8
Warm air volume Over 0.2m3/min Warm air temperature 6-level adjustment Drying Heating power 200W device Thermal fuse, Thermostat, Leakage protection Safety device plug Surface temperature 6-level adjustment Heating power Heated seat After 10 minutes of use, the seat temperature Burn protection will automatically drop slowly to a low level Seat sensor, Temperature sensor, Thermostat, Safety device...
Page 9
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
List of materials Main Unit Remote Control Components Sealing Flange Install Cardboard Installation Manual NPT 1/2 Installation Manual Three way angle valve Mounting Kit...
Technical drawing 27-44/69'' The drawing is for reference only, and we reserve the right to modify the product appearance. Product appearance is subject to change in kind.
Parts identification Left side Bumper Seat Button Ceramic toilet Right side Nozzle shield Dryer shield Night light sensor window Front Rear washing washing Spray nozzle Touch the sensing area with foot...
Toilet installation Install the matching three-way angle Mounting bracket installation valve • Assemble the mounting bracket with bolts and then install them to the pre-installed • Mark the center line of the sewage outlet flange plate on the ground and lock tight on the ground, and install a three-way with nuts.
Page 14
5. Screw installation Connect the hoses • Put the screw through the fixing sleeve • Connect the water supply hose of the and then install it through the holes (on toilet tank and the water inlet hose of the both sides of the toilet bowl) to the toilet seat to the three-way angle valve as mounting bracket on the ground.
Preparation Turn on the three-way angle valve • Check the threaded connection for leaks to ensure complete sealing. Turn the three-way angle valve counterclockwise to the full open position. (Note: The three-way angle valve opens with a large torque for the first time.) Equipped with three-way angle valve...
Auto open/close lid The intelligent toilet can achieve the function of auto lid open/close. On closed situation, so please function the auto lid open/close function by using remote controller. 1. Approaching the toilet When user enters the sensing range, the seat lid opens automatically.
Foot sensor The toilet is equipped with foot sensor lid-open function, it can make lid auto- open by sensing foot movement. When the lid and seat are both closed, touch the sensing area with foot to open the lid. Seat When the lid is open and seat closed, touch the sensing area with foot to open the seat.
Maintenance Main unit care and maintenance Spray nozzle care and maintenance Shut off power supply before doing When no one is seated, turn the knob maintenance. clockwise. The nozzle will automatically stretch out to allow access for cleaning. Use only a soft, damp cloth to clean. Avoid using harsh chemicals.
Emergency troubleshooting Power and water failure Product unused for a period of time • Fill up 2.1Gal (8L) water to a bucket and • When the product is left unused for a long flush the ceramic bowl. time, especially in cold weather, it is highly recommended to drain the water to Note: Avoid water spilling from bowl.
Page 20
Outside the above functions, short press the knob to perform the toilet flushing function. EP-U8PRO/U9PRO EP-U8PRO/U9PRO 7. In operating mode (when no one is sitting), press and hold the knob to enter the standby state.
Description of the top indicator lights ① ② ③ ④ The power-on self-test is completed. Intelligent night light: When the intelligent night light state is turned on, the ① night light indicator light is on, otherwise it is off. Water temperature: The indicator light is on when the water temperature is in ②...
Troubleshooting guide Problem Cause Solution Water supply hose is kinked Straighten the hose to remove the kink No water Angle valve is off Turn on the angle valve from nozzle A water failure occurred Restore the water supply Water supply hose is kinked Straighten the hose to remove the kink Angle valve is not fully Poor water...
Product warranty card Model No. Customer Name Seller Purchasing Date Invoice No. Customer Contact Distributer Stamp Distributer Phone Thank you for choosing our product. This product is warranted for three (3) years since the purchasing date for free repair of problems arising out of defects in workmanship while using in accordance with installation manual and usage cautions for intended purposes.
Page 24
The picture of product may not be entirely consistent with actual appearance and color because of product improvements, please in kind prevail. ASVFAF0162000A-1.0...
