- Page 1 ENJOY SMART LIFE Installation Manual Model: EP-E18MAX/EP-F19MAX Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. E-mail:service@eplo.com...
-
Page 2: Table Of Contents
Content Safety instructions FCC Statement IC Statement Technical specification List of materials Technical drawing Parts identification Toilet installation Installation of Wall-Mounted Control Pad Preparation Auto open/close lid Foot sensor Maintenance 1. Main unit care and maintenance 2. Spray nozzle maintenance and care 3. -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. - Page 4 Keep the cord away from heated surfaces. Never use while sleeping or drowsy. Never drop or insert any object into any opening or hose. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered. Connect this product to a properly grounded outlet only.
-
Page 5: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Indicates that failure to follow the instruction may cause body CAUTION – injury or property damage. Do not install or use the product in wet places as steam room etc. It is recommended to use water-proof electrical outlet which should be installed in a place where is not easily to get wet. - Page 6 11. L'exposition directe au soleil est interdite. 12. Utilisez uniquement de l'eau du robinet ou de l'eau potable, sinon vous risquez de causer des éraflures. 13. Ne raccordez pas l'alimentation en eau à la sortie de l'appareil de chauffage. S'assurer que la température de l'eau d'entrée est comprise entre 3~35℃/37.4~95℉.
-
Page 7: Fcc Statement
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera- tion. -
Page 8: Technical Specification
Technical specification Rated voltage 110V-120V, 50Hz-60Hz Rated power 875W Main Unit Water proof IPX4 Power cord length About 1.5m Flush volume 1.6/1.1Gpf, 6.0L(full flush)/4.1L(half flush) Flushing mode Siphonic jet Rough-in 305mm Toilet Outlet outside diameter ≤100mm Drainage method S-trap Water pressure range 0.08MPA-0.8MPa (static pressure) Heating mode Instant... -
Page 9: Heated Seat
Deodorization Deodorization method Photocatalyst-free Sanitation Sanitation device Plasma sanitation Surface temperature 6-level adjustment Heating power After 10 minutes of use, the seat Heated seat Burn protection temperature will automatically drop slowly to a low level Seat sensor, Temperature sensor, Thermal Safety device fuse, Thermostat, Leakage protection plug Night light assembly... -
Page 10: List Of Materials
List of materials Main Unit Remote Control Components Sealing Flange Installation Cardboard Installation Manual Braided Hose Installation Manual (Installed) NPT 1/2 Three way angle valve Mounting Kit Battery Box... -
Page 11: Technical Drawing
Technical drawing 693mm 1. The drawing is for reference only, and we reserve the right to modify the product appearance. 2. Product appearance is subject to change in kind. -
Page 12: Parts Identification
Parts identification Left side Bumper Seat Button Ceramic toilet Right side Dryer shield Rear washing Remote Front control sensor washing Spray nozzle Touch the sensing area with foot... -
Page 13: Toilet Installation
Toilet installation 1. Installation of angle valve 3. Installation of the Flushing Battery (Suitable for fuction with power off flush.) Draw drain outlet centerline on the floor. Install angle valve at proper position on Remove the male end (red) of the battery the wall according to the dimension of connector from the rear seat cover of the toilet. - Page 14 6. Ceramic toilet installation 4. Hose Install a sealing flange into drain outlet. Connect the water inlet and angle valve of the toilet with the matching hose and Install ceramic toilet on the corresponding tighten it. position. Connect the water inlet hose of the toilet seat Connect the water supply hose of the toilet tank...
-
Page 15: Installation Of Wall-Mounted Control Pad
Installation of Wall-Mounted Control Pad Holder Installation 1： 1. Drill two holes in the wall according to the installation position, with a diameter of 5mm(0.2in), a distance of about 50mm(2in), and a depth of about 25mm(1in). 2. Remove the adhesive backing from the back of the mounting bracket. 3. -
Page 16: Preparation
Preparation 1. Turn on the angle valve Check the threaded connection for leaks to ensure complete sealing. Turn the angle valve counterclockwise to the full open position. (Note: The angle valve opens with a large torque for the first time.) Angle valve 2. -
Page 17: Auto Open/Close Lid
Auto open/close lid The intelligent toilet can achieve the function of auto lid open/close. On closed situation, so please function the auto lid open/close function by using remote controller. 1. Approaching the toilet When user enters the sensing range, the seat lid opens automatically. -
Page 18: Foot Sensor
Foot sensor If the model you purchased is with foot sensor, 1. When the lid and seat are both closed, touch the sensing area with foot to open the lid. Seat 2. When the lid is open and seat closed, touch the sensing area with foot to open the seat. Seat 3. -
Page 19: Maintenance
Maintenance Spray nozzle maintenance and care Main unit care and maintenance When no one is seated, short press 1. Shut off power supply before doing “REAR/MOVE” Button on the main unit, maintenance. the nozzle will automatically stretch out 2. Use only a soft, damp cloth to clean. to allow access for cleaning. -
Page 20: Filter Maintenance
Emergency troubleshooting Power and water failure Filter maintenance Put around 2.1Gal (8L) water into a barrel If poor spray performance occurs under and flush the ceramic bowl. normal conditions: Note: Avoid water spilling from bowl. 1. Turn off power and the angle valve 2. -
Page 21: Product Unused For A Period Of Time
2.Battery replacement Product unused for a period of time Remove the battery box from the rear end When the product is left unused for a of the ceramic (as shown in the picture). long time, especially in cold weather, it is highly recommended to drain the Separate the upper and lower covers water to prevent freezing. -
Page 22: Description Of The Button Function
Description of the button function 1. When no one is seated, press and hold Stop Button to enter standby mode (white light off), press Stop Button again to return to functional mode (white light always on). In standby mode , except for the Stop Button on the main unit, the operation of any button (including the main unit and the remote control) is invalid. -
Page 23: Led Display Description
LED display description Sanitation Water temperature Temperature display Seat temperature ECO energy saving Description of LED display: 1. During self-inspection, icons of sanitation , water temperature, seat temperature and ECO light up, and the temperature is displayed at 88. After self-inspection, sanitation , water temperature, ECO icons and seat temperature icon are displayed according to working status. -
Page 24: Wall-Mounted Control Pad Usage Instruction
Wall-Mounted Control Pad Usage Instruction Half Flush Full Flush Open/Close the Seat Open/Close the Lid Half Flush/Full Flush · Short press " " button, the toilet starts half flushing. · Short press " " button, the toilet starts full flushing. Open/Close the Lid/Seat ·... -
Page 25: Troubleshooting Guide
Troubleshooting guide Problem Cause Solution Water supply hose is kinked. Straighten the hose to remove the kink. Angle valve is not fully Poor flushing Turn on the angle valve fully. turned on. Filter is dirty. Clean the filter. Angle valve is shut off. Turn on the angle valve. - Page 26 Problem Cause Solution Power off Turn on the power. The seat switch will not turn on unless the user is seated Sit back on the toilet seat. properly. Stuck due to impurities Remove impurities. Spray rod does not operate or Press the "STOP"...
- Page 27 Problem Cause Solution Night light Night light function is "OFF". Set to "ON". does not work The positive and negative direction of the batteries is Re-load batteries. Remote control incorrect. does not work Batteries have expired Load new batteries. Manual flushing cannot work during Replace new batteries for power failure power failure...
- Page 28 WWW.EPLO.COM WhatsApp The picture of product may not be entirely consistent with actual appearance and color because of product improvements, please in kind prevail. ASVFAF0401027A-1.0...
