- Page 1 ENJOY SMART LIFE Installation Manual Model: EP-U8MAX / EP-U9MAX Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. E-mail:service@eplo.com...
-
Page 2: Table Of Contents
Content Safety instructions Technical specification FCC Statement IC Statement List of materials Technical drawing Parts identification Toilet installation Preparation Auto open/close lid Foot sensor Maintenance 1. Main unit care and maintenance 2. Filter maintenance 3. Spray nozzle care and maintenance Emergency troubleshooting 1. - Page 3 IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
- Page 4 Keep the cord away from heated surfaces. Never use while sleeping or drowsy. Never drop or insert any object into any opening or hose. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered. Connect this product to a properly grounded outlet only.
-
Page 5: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Indicates that failure to follow the instruction may cause body injury or CAUTION – property damage. Do not install or use the product in wet places as steam room etc. It is recommended to use water-proof electrical outlet which should be installed in a place where is not easily to get wet. - Page 6 9. Le produit est équipé d'un couvercle de siège à fermeture douce. Ne fermez pas le siège de toilette, il pourrait causer des dommages. 10. N'utilisez pas de produits chimiques agressifs ou de brosses pour nettoyer ce produit. 11. L'exposition directe au soleil est interdite. 12.
-
Page 7: Technical Specification
Technical specification Model EP-U8MAX / EP-U9MAX Rated voltage 110V-120V, 50Hz-60Hz Rated power 875W Main Unit Water proof IPX4 Power cord length About 1.5m Flush volume 1.6/1.1Gpf(6.0/4.1Lpf) Flushing mode Siphonic jet Rough-in 12 inches (305mm) Toilet Outlet outside diameter ≤ 3.9 inches (≤ 100mm) - Page 8 Warm air volume Over 0.2m3/min Warm air temperature 6-level adjustment Drying Heating power 200W device Thermal fuse, Thermostat, Leakage protection Safety device plug, Wind temperature sensor Surface temperature 6-level adjustment Heating power Heated seat After 10 minutes of use, the seat temperature Burn protection will automatically drop slowly to a low level Seat sensor, Temperature sensor, Thermostat,...
-
Page 9: Fcc Statement
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera- tion. -
Page 10: List Of Materials
List of materials Main Unit Remote Control Components Sealing Flange Rough-in Template Installation Manual Installation Manual Filling funnel NPT 1/2 Three way angle valve Mounting Kit Foaming Agent Battery Box... -
Page 11: Technical Drawing
Technical drawing (702mm) ” The drawing is for reference only, and we reserve the right to modify the product appearance. Product appearance is subject to change in kind. -
Page 12: Parts Identification
Parts identification Left side Bumper Foam shield filling drawer Seat knob Ceramic toilet Right side Nozzle shield Dryer shield Night light sensor window Front Rear washing washing Spray nozzle Touch the sensing area with foot (optional) -
Page 13: Toilet Installation
Toilet installation Install the matching three-way angle 3. Installation of the flushing battery valve 1. Remove the male end (red) of the battery connector from the rear seat cover of the • Mark the center line of the sewage outlet ceramic. - Page 14 Mounting bracket installation 6. Screw installation • Assemble the mounting bracket with bolts • Put the screw through the fixing sleeve and then install them to the pre-installed and then install it through the holes (on flange plate on the ground and lock tight both sides of the toilet bowl) to the with nuts.
- Page 15 Connect the hoses •Put the funnel into the filling port, hold it, and slowly pour the foam liquid into the • Connect the water supply hose of the funnel with the other hand. (Do not quickly toilet tank and the water inlet hose of the pour the foam liquid into the funnel to toilet seat to the three-way angle valve as avoid the foam liquid overflowing)
-
Page 16: Preparation
Preparation Turn on the three-way angle valve • Check the threaded connection for leaks to ensure complete sealing. Turn the three-way angle valve counterclockwise to the full open position. (Note: The three-way angle valve opens with a large torque for the first time.) Equipped with three-way angle valve... -
Page 17: Auto Open/Close Lid
Auto open/close lid Only for the product with lid auto opening/closing function. If the auto lid open/close function is disabled, please use the remote control to enable this function. 1. Approaching the toilet When user enters the sensing range, the seat lid opens automatically. -
Page 18: Foot Sensor
Foot sensor If the model you purchased is with foot sensor, When the lid and seat are both closed, touch the sensing area with foot to open the lid. Seat When the lid is open and seat closed, touch the sensing area with foot to open the seat. -
Page 19: Maintenance
Maintenance Main unit care and maintenance Spray nozzle care and maintenance Shut off power supply before doing When no one is seated, turn the knob maintenance. clockwise. The nozzle will automatically stretch out to allow access for cleaning. Use only a soft, damp cloth to clean. Avoid using harsh chemicals. -
Page 20: Emergency Troubleshooting
Emergency troubleshooting Power and water failure Product unused for a period of time Long press the knob on the main unit to • When the product is left unused for a long time, especially in cold weather, it is highly flush. -
Page 21: Failure Of Remote Control
Failure of remote control Replace the flushing battery Remove the battery box from the rear end Operate via knob on the main unit. of the ceramic (as shown in the picture). Separate the upper and lower covers of the battery box, press the hook on the battery cable plug and unplug the battery Knob cable plug to remove the old battery... -
Page 22: Description Of The Knob Function
Description of the knob function Knob Anticlockwise Clockwise definition rotation rotation Knob Push the knob function In the seated state, turn the knob clockwise to start the feminine wash function, and turn it counterclockwise to start the rear wash function. Rear wash/ If you short press the knob during cleaning, the current function will front wash... -
Page 23: Description Of The Top Indicator Lights
Description of the top indicator lights ① ① ② ② ③ ① ECO energy saving ① Seat temperature Seat temperature display ② Water temperature ② ③ Water temperature display 1. During the power-on self-test phase, the water temperature, seat temperature, and ECO icons light up, and the temperature displays 88°F. -
Page 24: Troubleshooting Guide
Troubleshooting guide Problem Cause Solution Water supply hose is kinked Straighten the hose to remove the kink No water Angle valve is off Turn on the angle valve from nozzle A water failure occurred Restore the water supply Water supply hose is kinked Straighten the hose to remove the kink Poor water Angle valve is not fully... - Page 25 Problem Cause Solution User is not within the Adjust position on seat to activate the sensing area of the seat sensor Malfunction of It is normal for the deodorizing function deodorization Deodorization function to continue operating after user leaves, continues after user leaves for complete odor removal Foam shield has a small amount of...
- Page 28 The picture of product may not be entirely consistent with actual appearance and color because of product improvements, please in kind prevail. ASVFAF0401025A-1.0...
